Eaton Cutler-Hammer Easy-Start ES Series User Manual

Easy-Start ES Instruction Manual
Options
SECTION 4
4-7
Available Options
Circuit Breakers
Circuit Breaker Interrupting Rating and Terminal Sizes
Table 4-3
Circuit UL489 Interrupting Capacity Rating
Breaker Type Max Breaker Wire Range
Amps Terminals
240V 480V 600V
HFD 100 100,000 65,000 25,000 #14 -1/0
HFD 150 100,000 65,000 25,000 #4 - 4/0
HJD 250 100,000 65,000 25,000 #4 - 350 MCM
HKD 200 100,000 65,000 25,000 #3 - 350 MCM
HKD 250 100,000 65,000 35,000 250-500 MCM
HKD 300 100,000 65,000 35,000 250-500 MCM
HKD 400 100,000 65,000 35,000 3/0-250 MCM (2)
HMC 800 65,000 50,000 25,000 500-750 MCM (2)
HNC 1200 65,000 50,000 25,000 4/0 - 500 MCM (4)
