4. Operation
4.4 Overview of the menus on the device
4.4.3 Menu Parameter
This submenu lists the function blocks that are being used in the current program. This
makes it possible to change the values of constants in the program at runtime without
having to stop or re-transfer the program.
When the password is activated and the +/- basic parameter for each function block is
set, you can allow or deny the operator of the system the possibility to change the val-
ues.
Function blocks with basic parameters that you have set to + via the +/- character in
the function block editor are displayed in the PARAMETERS menu and can be changed.
It is only possible to change constants. Other operands cannot be changed. It is also
possible to change parameters via the PARAMETERS menu if you have saved the pro-
gram and therefore password protected the function block editor.
To immediately apply a change to the individual constants, press the OK button. Press
the ESC button to cancel the change instead.
List of function blocks in
the current program,
e.g.,
The current program
does not use any func-
tion blocks
STOP✓ RUN
PARAMETERS
SETCLOCK
CARD
INFORMATION
SYSTEM-OPT.
PROGRAM
Table 12: Parameter
T 01
Ü
S +
C 02
L:1 STOP
Table 13: Parameter
CONTAINS NO
FUNCTION BLOCKS
Table 14: Parameter
Pressing the OK button will show the parameters for the individual function blocks in an
additional submenu that can be used to modify these parameters with the cursor but-
tons.
T 01
Ü
S +
>I1 000 800
>I2 009 200
QV> 000 000
..
Table 15: Time function
block example
96
easyE4 11/18 MN050009 EN www.eaton.com
