26
6.3 Glossary
Bypass AC input Bypass line from the AC power source, controlled by the UPS, used to directly supply the
load if an overload or a malfunction occurs on the UPS.
Backup time Time during which the load can be supplied by the UPS operating on battery power.
Battery test Internal UPS test to check battery status.
Equipments Devices connected to the UPS output.
Excessive discharge Battery discharge beyond the permissible limit, resulting in irreversible damage to the
battery.
FlexPDU Module with UPS outlets for installation in a bay. There are different modules with dif-
ferent types of outlets.
Frequency converter Operating mode used to convert the AC power frequency between the UPS input and
output (50 Hz -> 60 Hz or 60 Hz -> 50 Hz).
HotSwap MBP UPS manual-bypass module for maintenance. There are different modules with differ-
ent types of outlets.
Low-battery warning This is a battery-voltage level indicating that battery power is low and that the user
must take action in light of the imminent break in the supply of power to the load.
LCD Liquid Crystal Display.
Normal AC input The AC power line supplying the UPS under normal conditions.
Percent load Ratio of the power effectively drawn by the load to the maximum output of the UPS.
Personalization It is possible to modify certain UPS parameters set in the factory. Certain UPS functions
can also be modified by the Personal Solution-Pac software to better suit user needs.
Programmable These outlets can be automatically shut down during operation on battery power
Outlets (shutdown time delays can be programmed with the Personal Solution Pac software).
The UPS has two sets of two programmable outlets.
Start on battery The devices connected to the UPS can be started even if AC power is not available.
power The UPS operates on battery power alone.
UPS Uninterruptible Power Supply.
UPS ON/OFF This function enables or disables initiation of UPS ON/OFF control sequences by
Controlled by computer pwower management software.
software
86-86710-00EN A02 - Page 31
86-86710-00 A02 UM.indd 31 14/01/2009 10:56:32
6.2 Programming the Programmable Outlets
1. To open the Setting window, left-click on Start Menu / Programs / EATON / Personal Solution Pac / Settings,
or right-click on the PSP power plug located in the SYS Tray.
2. Click on the “+” symbol next to “UPS Settings” to expand the “UPS Settings” section.
3. Click on “Startup Timer” and change the “The group of outlets restarts after” to “0” to have powershare outlet
provide power at the same time the as main outlets.
86-86710-00EN A02 - Page 28
6. Appendices
86-86710-00 A02 UM.indd 28 14/01/2009 10:56:32
