Eaton Matrix 2000 User Manual

Matrix Standalone Inverter
6
Copyright © 2017 Eaton Corporation. All Rights Reserved.
IPN 997-00012-72C July 2017
The Matrix 2000 includes the following accessories:
 4 x M4 screws to connect the brackets to the rack
 2 x 19-inch rack mount brackets (factory-fitted)
 2 x 23-inch rack mount brackets
Mounting
1 If the Matrix 2000 is to be mounted in a 23-inch rack:
 Remove the factory-fitted 19-inch rack mount brackets.
 Attach the 23-inch rack mount brackets.
2 Mount the Matrix 2000 in the rack:
 Fit cage nuts in the rack.
 Position the Matrix 2000.
 Align the holes of mounting brackets and rack.
 Secure with four cross screws provided.
AC Connections

 The ground wire of the ac input must be connected to the ground from your ac utility
source.
 The ground wire of the ac output must be connected to the grounding point for your loads.
 Do not operate the unit without connecting it to ground. Electrical shock hazard may
result.
1 Refer to the Specifications on page 19 for the correct ac input and output plugs/sockets.
 120V models are supplied with an ac input cord and plug.
2 Either:
 For 230V models, connect an ac cord from the ac input plug to a nearby (easily
accessible) ac outlet.
or:
 For 120V models, connect the ac cord to a nearby (easily accessible) ac outlet.
3 Connect ac cords from the ac output plugs to the load equipment.
DC Connections
The maximum dc input current is 46.3A. The cables from the dc supply to the Matrix 2000 must
be in accordance with local electrical codes or regulations.
 Recommended input circuit protection: 60A.
 Recommended cable size: 6AWG/10mm
2
(copper).
 Increase the cable size if the dc supply is more than 10 feet/3m from the Matrix 2000.
Maximum cable size is 2AWG/25mm
2
.
 Cables that are too small or too long will cause decreased inverter performance such as poor surge
capability and frequent low input voltage warnings and shutdowns. These low input voltage
warnings are due to dc voltage drop across the cables from the inverter to the dc supply. The
longer and/or smaller these cables, the greater the voltage drop.
