Eaton Matrix 2000 User Manual

Chapter 1
General Description


Copyright © 2017 Eaton Corporation. All Rights Reserved.
IPN 997-00012-72C July 2017
1
C h a p t e r 1
General Descriptio n
Overview
Topic Page
Part Numbers 1
Front View 2
Rear Views 2
The Matrix Standalone Inverter is a 1U, 19-inch rack mount module with output up to
2000VA/2000W (at 110/115/120 or 208/220/230/240V ac, 50 or 60Hz) from -48V dc input.
The module has a built-in automatic transfer switch (ATS), high efficiency and a wide operating
temperature range.
Alarm and monitoring is provided by an LCD screen, alarm LEDs and an alarm relay output.
Part Numbers
Part Number
Description
INV-4820ESA
Matrix 2000, 2000VA/2000W standalone inverter module with
automatic transfer switch, 230V ac nominal output. 2 x IEC 320-C13
output sockets.
INV-4820SA
Matrix 2000, 2000VA/2000W standalone inverter module with
automatic transfer switch, 120V ac nominal output. 2 x NEMA 5-20R
output sockets. Includes AC input cord.
 For full details refer to the Specifications on page 19.

Eaton Matrix 2000 Specifications

General

Brand	Eaton
Model	Matrix 2000
Category	Inverter
Language	English
