Eaton Matrix 2000 User Manual

Operation
Copyright © 2017 Eaton Corporation. All Rights Reserved.
IPN 997-00012-72C July 2017
11
Press to display the Main Menu.
Press and then to select the Status or the Settings menu. See Menu structure on page 25.
Main Menu
> Status
Settings
Status Menu
Inverter Menu
Description
OPV
Output voltage of the inverter module (V)
OPI
Output current of the inverter module (A)
OPF
Output frequency of the inverter module (Hz)
OPP
Output power of the inverter module (VA)
Input Volt
DC input voltage of the inverter (V)
Power Used
Load level (%)
Ambient Temp.
Inverter Ambient temperature (ºC)
Power Limited
Power limited (%)
Mains AC Volt
Voltage of AC Input
Mains AC Freq
Frequency of AC Input
Priority
On-line/Off-line
Alarm Menu
Description
Inverter
Alarm number and name
Version and Number
Menu
Description
HW Ver
Hardware version of the inverter module
SW Ver
Software version of the inverter module
Serial No
Serial number of the inverter module
