Apply Power
1 If a remote control switch or relay contacts are connected (see details on page 7) then set
these to be OPEN.
See Remote Control Operation on page 10 to setup remote control operation.
2 Set the Matrix 2000 ON/OFF switch to the OFF (out) position.
3 Connect the dc input cables to the dc source according to the manufacturer's instructions.
Check for correct polarity.
4 Switch on the dc source. The Matrix 2000 will start.
A Mains Abnormal alarm will be active.
5 Connect the ac input (automatic transfer switch input).
The Mains Abnormal alarm will clear.
6 Press in the Matrix 2000 ON/OFF switch. The inverter ac output will start and the green
LED will turn on.
If the green LED is not on, or if any other LED is on or flashing then see Troubleshooting on
page 16.
7 Check all system parameters.
See Default Values on page 23 and Parameter Setting on page 13.
8 Check that the output ac voltage and frequency are correct.
See Part Numbers on page 1 for the output voltage of the different models.
9 Connect the ac load equipment to the ac outputs. Check the equipment is operating
correctly.
Remote Control Operation (Optional)
If a remote control switch or relay contacts are connected (see details on page 7), then:
1 Set the remote control switch or relay contacts to be OPEN.
2 If off, turn on the Matrix 2000 using the front panel ON/OFF power switch.
3 Close the remote control switch or relay contacts to turn off the Matrix 2000 (after a 0.5s
delay).
The green Power LED will flash.
4 Open the remote control switch or relay contacts to turn on the Matrix 2000 (after a 0.5s
delay).
Main Menu
With power on, the LCD will light and initially display "Waiting" during the self-diagnosis
mode. The general status screen then appears, as follows.
