Eaton Matrix 2000 User Manual

Matrix Standalone Inverter
12
Copyright © 2017 Eaton Corporation. All Rights Reserved.
IPN 997-00012-72C July 2017
Settings Menu
The inverter system allows some parameters to be set from the front panel.
1 Press then to select Settings.
2 A 4-digit numeric password is requested.
Password:
* * * *
Press to select the first digit. Press or to increase or
decrease the number. Then press .
 The initial password is 0000. No setting modification can be
executed if a wrong password is entered.
The Settings section is divided into two categories:
 Inverter - parameters related to the inverter functions
 System - system related setups.
Inverter Parameter Settings
Parameter
Setting Option
Output volt
Inverter output voltage
For 230Vac output:
1) 208 Vac; 2) 220 Vac; 3) 230 Vac; 4) 240 Vac
For 110Vac output:
1) 110Vac; 2) 115Vac; 3)120Vac
Output Freq
Inverter output frequency: 50Hz or 60Hz
OPV HL: High loss of
inverter output voltage
For Output volt = 230V, adjustable 220 - 276V
For Output volt = 110V, adjustable 117 - 138V
OPV LL: Low loss of
inverter output voltage
For Output volt = 230V, adjustable 176 - 230V
For Output volt = 110V, adjustable 90 - 115V
IPV LVSD
The minimum input voltage for inverter normal operation:
Adjustable 40 - 44V.
IPV HVSD
The maximum input voltage for inverter normal operation:
Adjustable 59 - 61V.
Power Limited
Inverter output power capacity:
Adjustable 50 - 100%.
Inverter On/Off
Turns the inverter output ON/OFF. The controller and the
static switch remain operational.
AC HL: High loss of AC
input
For Output volt = 230V, adjustable 220 - 276V
For Output volt = 110V, adjustable 117 - 138V
AC LL: Low loss of AC
input
For Output volt = 230V, adjustable 176 - 230V
For Output volt = 110V, adjustable 90 - 115V
