Cha pter 2 Installati on
2.1 Unpacking inspection
1. Open the packing box of the UPS and take it out, check whether the UPS is damaged
during the process of transportation or not.
2. Should any damage be observed or parts be found missing, do not start the machine.
Contact the forwarder and distributor immediately.
Accessories:
1) User manual (1 PCS)
DANGER: Cut off the input switch, if it is the long back up time model, disconnect
the battery input.
CAUTION：1. The installation as described in this chapter may only be carried out
by qualified technician, comply with the local electric law.
2. It is recommended to use the floor installation.
RECYCLE: Please keep the packaging for future use.
2.2 Wiring table
CAUTION: Choice of the diameter and cross section of conductors depend on the
rated power of UPS.
Model C-6000F/C-6000FL/C-6000FC/
C-6000FCL
C-10000F/C-10000FL/C-10000FC/
C-10000FCL
Input
G
12AWG or 14 mm
2
(hard wire) 10AWG or 22 mm
2
(hard wire)
N
12AWG or 14 mm
2
(hard wire) 10AWG or 22 mm
2
(hard wire)
L
12AWG or 14 mm
2
(hard wire) 10AWG or 22 mm
2
(hard wire)
Battery
+
12AWG or 14 mm
2
(hard wire) 10AWG or 22 mm
2
(hard wire)
-
12AWG or 14 mm
2
(hard wire) 10AWG or 22 mm
2
(hard wire)
G
12AWG or 14 mm
2
(hard wire) 10AWG or 22 mm
2
(hard wire)
Output
*
L
12AWG or 14 mm
2
(hard wire) 10AWG or 22 mm
2
(hard wire)
N
12AWG or 14 mm
2
(hard wire) 10AWG or 22 mm
2
(hard wire)
G
12AWG or 14 mm
2
(hard wire) 10AWG or 22 mm
2
(hard wire)
*.6kVA: for 110V output, please use conductor of 8AWG or 22 mm
2
or above ( hard wire).
10kVA: for 110V output, please use conductor of 6AWG or 38 mm
2
or above ( hard wire).
