Eaton ON-LINE Series User Manual

30
COMMAND
CONFIGURATION
HELP
HELP
SERVICE
RUN RECORD
OTHERS
1. Select "Help" and press Enter. 2. Select the following items and press
Enter to obtain the information of service
hotline, run record or inverter temperature.
1. The following screen can be obainted
when selftest is enabled (UPS works in line
mode or conversion mode and there is no
"battery voltage low" issue).
2. Users can define the testing time or
choose 10S.
COMMAND
SELFTEST
HELP
SELFTEST
TEST FOR 10S
TEST AS SPEC
TEST UNTIL 80%
6. The following screen can be obtained if
selftest fails.
SELFTEST FAIL
PRESS ANY KEY...
3. Press Enter.
CONFIRM
TEST FOR 10S
NO, CANCEL
YES, CONFIRM
4. The following screen can be obtained
when UPS is self-testing.
CONFIRM
CANCEL TEST
NO, CANCEL
YES, CONFIRM
5. It switches to state screen as follows
when selftest is completed.
LOAD: 100%
I P VOLT: 220.0V
BAT VOLT: 260V
STATE: BYPASS
3.6 Help
3.7 Self test
