Eaton ON-LINE Series User Manual

36
(Battery mode)
(Bypass mode)
• The battery LED indicators are turned on and the line LED is turned off. Battery
supplies power to the load.
• In battery mode, the buzzer beeps once every 4 seconds, press the function button
more than 2 seconds to silence the audible alarm.
4.3 Shut down
• Press the “OFF” button more than 1 second to shut down the UPS.
• The terminal still have live voltage via bypass, and LED status is as follows.
• In bypass mode, the bypass LED indicator is lit and the buzzer beeps once every 2
minutes, press the function button more than 2 seconds to silence the audible alarm.
• To completely power down the UPS, disconnect the line input of the UPS.
