EDAN SD3 Series User Manual

SD3 Series Ultrasonic Pocket Doppler User Manual Doppler and Accessories
- 10 -
SD3 PRO/SD3 PLUS SD3/SD3 LITE/ SD3 VASCULAR
Figure 2-2 Rear Panel Figure 2-3 Left Panel
Figure 2-4 Top Panel Figure 2-5 Right Panel
1
Display Panel (SD3
PRO/SD3/SD3 PLUS)
2
Speaker
3
Working State Indicator
(SD3 LITE/SD3 VASCULAR)
4
Battery Compartment
(SD3 PLUS/SD3 PRO)
5
Charge Stand Socket
(SD3 PLUS/SD3 PRO)
6
Battery Compartment (SD3
LITE/SD3/ SD3 VASCULAR)
7
Volume Control
8
Probe Holder
9
Probe
10
Probe Socket
11
Audio Socket (SD3
PRO)
12
Charge Socket (SD3 PLUS/SD3
PRO)
13
Record Button
(SD3 PRO)
14
Earphone Socket (SD3
LITE/SD3/SD3 PLUS/
SD3 VASCULAR)
2.2.2 Display Panel
For SD3, SD3 PRO, and SD3 PLUS, the OLED is shown as follows:
14
10
11
12
13
8 9
4
5
6
7
4
5
6
7
