Errors
If the facility is shut down, then a
warning signal (
) and a blinking
error code is displayed on screen. The
causeoftheshutdownmustrstbe
remediated, before one can proceed
with a reset of the THISION S PLUS
boiler. The attached to list shows
possible reasons for shutdowns and
the possible cause of the malfunction.
Code Description of the error
0 No error
10 Outdoor temperature sensor error
20 Boiler temperature 1 - sensor defect
26 Joint inlet temperature sensor error
28 Smoke/ waste gas temperature sensor error
30 Inlet temperature 1 - sensor defect
32 Inlet temperature 2 - sensor defect
38 Inlet temperature of pre-controller sensor error
40 Return temperature 1 - sensor defect
46 Return temperature cascade sensor error
47 Joint return temperature sensor error
50 Drinking water temperature 1 sensor error
52 Drinking water temperature 2 sensor error
54 Drinking water pre-controller sensor error
57 Drinking water circulation temperature sensor error
60 Room temperature 1 - sensor defect
65 Room temperature 2 - sensor defect
70 Bu󰀨ertanktemperature1sensorerror
71 Bu󰀨ertanktemperature2sensorerror
72 Bu󰀨ertanktemperature3sensorerror
73 Collector temperature 1 sensor error
74 Collector temperature 2 sensor error
82 LPB address collision
83 BSB wire short-circuit
84 BSB address collision
85 BSB radio communications error
91 EEPROM error with locking information
98 Expansion module 1 error (combined error)
99 Expansion module 2 error (combined error)
100 Two master clocks (LPB)
102 Master clock without power reserve (LPB)
103 Communications error
105 Maintenance report
109 Boiler temperature monitoring
110 Safety temperature limiter defect shutdown
111 Temperature monitor shutdown
119 Safety thermostat of burner door interrupted
121 Flow temperature 1 (heating circuit 1) monitoring
122 Flow temperature 2 (heating circuit 2) monitoring
125 Pump monitoring error
126 Drinkingwaterllingmonitoring
127 Anti-legionella temperature not reached
128 Flame failure during operations
129 Fan failure or air pressure monitor error
130 Limit value of waste gas temperature exceeded
131 Burner malfunction
132 Gas pressure monitor or air pressure monitor error
133 Noameduringsafetyinterval
146 Congurationerrorgroupreport
151 Internal error
152 Parameterization error
153 Facility manually locked
160 Fan error
162 Air pressure monitor error - does not close
164 Heatingcircuitowswitcherror
166 Air pressure monitor error - does not open
171 Alarm contact H1 or H4 active
172 Alarm contact H2 (EM1, EM2 or EM3) or H5 active
173 Alarm contact H6 active
174 Alarm contact H3 or H7 active
178 Temperature monitor heating circuit 1
