80
Use instructions
“017 TIMEOUT SLAVE AMPLIFIER”
This indicates that one or more amplifiers
have communication problem.
“018 EXCITER 1 FAULT”
This indicates that exciter 1 is fault.
“019 EXCITER 2 FAULT”
This indicates that exciter 2 is fault.
“020 UPS ACTIVE”
This indicates that UPS is active.
“021 SW INTERLOCK INCORRECT WORK”
This indicates an interlock signals hardware
failure.
“022 EXCITERS FAULT”
This indicates that both exciters are fault.
“023 WORKING MODE COMBINED”
This indicates the machine operation in a
combined system.
“024 USER ENV TEMP OUT LIMIT”
This indicates a deviation from the conditions
to set by user in relation to environment tem-
perature measured from the apparatus.
“025 USER RF TEMP OUT LIMIT”
This indicates a deviation from the conditions
to set by user in relation to RF modules tem-
perature.
“026 USER FRW PWR OUT LIMIT”
This indicates a deviation from the conditions
to set by user in relation to forward power.
“027 USER RFL PWR OUT LIMIT”
This indicates a deviation from the conditions
to set by user in relation to reflected power.
“028 NO AUDIO”
This indicates the absence of the audio signal.
“029 TIMEOUT SLAVE AMPLIFIER 1”
This indicates that amplifier n.1 have commu-
nication problem.
“030 TIMEOUT SLAVE AMPLIFIER 2”
This indicates that amplifier n.2 have commu-
nication problem.
“031 TIMEOUT SLAVE AMPLIFIER 3”
This indicates that amplifier n.3 have commu-
nication problem.
“032 TIMEOUT SLAVE AMPLIFIER 4”
This indicates that amplifier n.4 have commu-
nication problem.
“033 TIMEOUT SLAVE AMPLIFIER 5”
This indicates that amplifier n.5 have commu-
nication problem.
“034 TIMEOUT SLAVE AMPLIFIER 6”
This indicates that amplifier n.6 have commu-
nication problem.
“035 ETG 1 TIMEOUT/TYPE INCORRECT”
This indicates that exciter n.1 have communi-
cation problem/not used the correct driver.
“036 ETG 2 TIMEOUT/TYPE INCORRECT”
This indicates that exciter n.2 have communi-
cation problem/not used the correct driver.
“038 ON LOCAL ETG”
This indicates that the exciter is in LOCAL
mode.
“040 SWR FOLDBACK”
This indicates that the machine is having a
power reduction since the reflected power
detected is too high.
3.2.2 Amplifier alarms/events list
Allarme/evento Descrizione
“AMP_000 CORRECT WORKING”
This indicates correct equipment operation.
The “On air” event has higher priority.
“AMP_001 SYSTEM RESET”
This indicates that the alarm reset is in
progress. All stored and inactive alarms are
removed from the list.
“AMP_002 EEPROM CHKSUM ERROR”
This indicates that the stored data is not relia-
ble any longer and the machine is reconfigu-
red according to the default parameters.
“AMP_003 BLOCKED”
This indicates that the machine is blocked
after making 5 restore attempts. the user
must reset in order to allow the equipment to
restart.
“AMP_004 STOP”
This indicates that the equipment is in stand-
by mode and is ready to start without alarms.
