5-2 Main Camera
Item Specifications
Lens
f = 4.0mm – 48.0mm (12x zoom) F3.2 – 3.6
Frame rate 30fps
Shooting area
Max. Min.
1080p
420mm x 233mm 48.5mm x 27.5mm
720p 420mm x 233mm 48.5mm x 27.5mm
SXGA 420mm x 334mm 48.5mm x 38.5mm
WXGA 420mm x 259mm 48.5mm x 30.5mm
XGA 420mm x 313mm 48.5mm x 36.5mm
Limit of focus
adjustment
From lens surface:
50mm (2.0 in) –
∞
(f=4.0mm – 23.4mm)
200mm (7.9 in x) –
∞
(f=23.4mm and higher)
Optical zoom 12X
Digital zoom 8X
Focus Auto/Manual/Zoom Sync
Image pick-up
element
1/2.8" CMOS
Total pixels Horizontal 2144, Vertical 1588
Effective pixels Horizontal 1920, Vertical 1536
Synchronized signal Internal
Resolution
Analog RGB Horizontal 800TV lines or more Vertical
800TV lines or more
Video output Horizontal 500TV lines or more
Analog RGB output
Analog RGB output 0.7 V (p-p)
75
Ω
unbalanced
Synchronized signal
SXGA : Positive polarity
WXGA : Horizontal
negative polarity,
Vertical positive
polarity
XGA : Negative polarity
1080p : Positive polarity
720p : Positive polarity
SXGA: 1280x1024@60Hz
Horizontal frequency: 63.981kHz
Vertical frequency: 60.020Hz
WXGA: 1280x800@60Hz
Horizontal frequency: 49.306kHz
Vertical frequency: 59.910Hz
XGA: 1024x768@60Hz
Horizontal frequency: 48.363kHz
Vertical frequency: 60.004Hz
1080p: 1920x1080@60Hz
Horizontal frequency: 67.50kHz
Vertical frequency: 60.00Hz
720p: 1280x720@60Hz
Horizontal frequency: 45.00kHz
Vertical frequency: 60.00Hz

Elmo TT-12 Specifications

General

Brand	Elmo
Model	TT-12
Category	Document Camera
Language	English
