5 Installation and commissioning
Topics covered in this chapter:
•
CSA - General safety
• Mounting
•
Hints for installation and connection
•
Adjustment of measuring chains at the machine
•
Mutual influences of two measuring chains
5.1 CSA - General safety
Equipment to be installed within another enclosure which provides the safety aspects and
protects the operator from hazards and is suitable for outdoor environment conditions.
5.2
Mounting
Mount the EZ 1000 converter into a suitable housing that contains a mounting rail of type
NS 35/7.5. The minimum space on the DIN rail is equal to the converter width of 26 mm.
The minimum mounting space for the EZ 1000 within a housing is shown in
Figure 5-1
.
Note
Ensure that there is no heated surface beneath the EZ 1000.
