11 Technical data
Topics covered in this chapter:
• Input
• Supply
• Output
•
Errors and tolerances
Only specifications with indicated tolerances or limit values are required. Data without
tolerances or without error limits are informative data and not guaranteed. Technology is
under constant development, and specifications are subject to change without notice. If
not otherwise specified, all data refer to a nominal supply voltage of -24 V and an
environmental temperature of +23°C.
11.1
Input
Sensor connector for eddy current
sensors
EZ 105x and EZ 108x
Third party sensors which meet the technical
requirements of the sensor input such as:
BN 33010x
Connector For plugs with cap nut.
Protection against short circuit Yes
11.2
Supply
Overvoltage protection Yes, maximal voltage -60 V DC
Reverse connect protection Yes
Nominal supply voltage -24 V
Permissible voltage range -20 V to -32 V
Nominal supply current 12 mA
Load resistor 100 k
