1-2 • E2 RX/BX/CX I&O Manual 026-1614 Rev 4 5-JAN-2013
1.2 The E2 Building
Controller (BX)
The counterpart to the E2 RX is the E2 BX, which con-
trols HVAC systems for low-rise retail, industrial, and
commercial buildings. The BX’s primary function is to
provide energy-efficient control of air handling units
(AHUs), rooftop units (RTUs), and other systems related
to environment control. In addition, the BX provides
extensive sensor control, logging, and graphing features
that allow the user to view accurate real-time information
about system conditions. The BX is equipped with many
power monitoring and demand control features that give
you the information you need to keep your site’s energy
consumption low.
The E2 BX is available in two models: the BX-300 and
BX-400. The only significant difference between the E2
BX-300 and the E2 BX-400 is the total number of building
control devices that may be operated by a single controller.
Table 1-2 shows the differences between capabilities for
the BX-300 and BX-400.
ESR8 ESR Control 0 99 99
Flexible Combiner 64 128 128
Heat/Cool Control 0 16 16
Holiday Schedule 4 64 64
Impulse 0 48 64
Infrared Leak Detection 1 16 16
K5 Ref Scroll 0 31 31
Logging Group 8 32 32
Loop/Sequence Control 4 16 24
Modular Chiller Control 0 1 2
MultiFlex ESR 0 31 31
MRLDS 24 24 24
Performance Alert 0 63 63
Power Monitoring 1 16 16
Pulse Accumulator 0 16 16
RMS Asset 99 99 99
Standard Circuit 48 48 64
Suction Group 4 4 4
TD Condenser Fan Con-
trol
4 64 64
TD3 Controller 0 99 99
Time Schedule 4 64 64
Capabilities
RX-
100
RX-
300
RX-
400
Table 1-1 - RX-100, RX-300, and RX-400 Comparison
Capabilities BX-300 BX-400
Advanced Rooftop
Control
32 32
AHU 6 8
Analog Combiner 128 128
Analog Import Point 64 64
Analog Sensor Control 64 72
Anti-Sweat 16 48
Control Link ACC 16 48
Control Link Case Disp 99 99
Control Link RSC 99 99
Copeland CoreSense
Communications
31 31
CT Drive 16 16
Demand Control 2 2
Digital Combiner 128 128
Digital Sensor Control 64 72
E2 Alarm Panel 7 7
Energy Meter 30 30
Flexible Combiner 128 128
Heat/Cool Control 16 32
Table 1-2 - BX-300 vs. BX-400 Comparison
