Micro Motion
®
Model D and DT Sensors Instruction Manual 1
Before You Begin
Your new sensor
Your new Micro Motion
®
Model D or DT sensor, or D600 sensor and
booster amplifier, is one part of a Coriolis flowmetering system. The
other part is a transmitter.
Transmitter connections
Model D sensors are available with a factory-supplied 9-wire junction
box for connecting to a remotely mounted transmitter, or to a remotely
mounted core processor.
Model DT sensors are available with a 3-foot (1-meter) pigtail of cable
that connects to a user-supplied junction box. The junction box connects
to a remotely mounted transmitter, or to a remotely mounted core
processor.
The D600 has a booster amplifier. The booster amplifier is available with
a factory-supplied 9-wire junction box for connecting to a remotely
mounted transmitter, or with a factory-supplied core processor for
connecting to a 4-wire remotely mounted transmitter or to a user-
supplied remote host.
All Model D and DT sensors may be connected to the Micro Motion
transmitters listed in Table 1. The D600 sensor may be connected to the
transmitters listed in Table 2.
Table 1. Transmitter and sensor compatibility guide
Transmitter
Model D sensor
(factory-supplied junction box)
Model DT sensor
(user-supplied junction box)
Model 1700/2700 (9-wire) X X
Model 3500/3700 (9-wire) X X
RFT9739 (7- or 9-wire) X X
IFT9701 (9-wire) X
(1)
RFT9712 (7- or 9-wire) X X
(1)Except D600.
