Time/Date Setup Quick Setups for Hand-Held Terminal (HHT) • 47
9 Quick Setups for
Hand-Held
Terminal (HHT)
Summaries of Zone Setup and Date/Time Setup have
been included here for your convenience. For more
detailed information about these setup procedures,
please refer to their respective sections in this manual.
9.1. Time/Date Setup
Time and date is set from the CONFIG OPTION
screen.
1. From the Home screen (F1), press the down
arrow key three (3) times to display the
OPTION screen:
2. Press the right arrow key and select 3.
3. Press the down arrow key twice to display the
CONFIG OPTION screen:
4. Press the right arrow key and select 2.
5. Press the down arrow key twice to open the
TIME/DATE screen:
A change in the Time/Date on any one of the RLDS
controllers changes ALL of the RLDS controllers on
the network.
6. Press the right arrow key to edit the fields. The
right and down arrow keys scroll downward
through the list, while the left or up arrow keys
will backspace the arrow so you may go back
to change a field.
7. Press the up arrow key to scroll back up to the
CONFIG OPTION screen to calibrate gases.
Your changes are saved and the data is written
when you scroll back up to the CONFIG
OPTION screen.
9.2. Zone Setup
9.2.1. General Configuration 1
Screen
1. From the CONFIG OPTION screen, press the
right arrow key and then press the 1 key for
RLDS CTRL.
2. Press the down arrow key twice to display the
General Configuration 1 screen:
3. Press the down arrow key to display the
General Configuration 2 screen:
NOTE: There is a short interval after the mes-
sage WAITING ON READ FROM RLDS.
OPTION: 1
1 = RLDS STATUS
2 = RLDS FAULTS
3 = RLDS CONFIG
CONFIG OPTION: 1
1 = RLDS CTRL
2 = TIME/DATE
3 = CALIB GASES
1-DATE: xx-xx-xx
1-TIME: xx:xx:xx
NOTE: For TIME, enter military time only.
Ux: ENABLED:DISABLED
Ux- ZONES: 8
Ux- MODEL: 300
Ux- REV : 1.12
NOTE: x is the RLDS currently being ac-
cessed.
