62 • RLDS I&O Manual 026-1309 Rev 8
12.3. Einstein Setup for RLDS
Set dip switch 8 to OFF and follow the steps for set-
ting up RLDS units through the Einstein controller in-
terface:
1. Log on.
2. Press F8 for ACTIONS.
3. Press Y for System Setup.
4. Press 4 for Network Status/Setup.
5. Press 2 for Connected I/O Boards &
Controllers to open the Network Setup
screen.
6. Under Boards on I/O Network, set the RLDS
number under IRLDS Controllers.
7. Press F9 HOME to go back to the Home
screen.
8. Set the Gateway to 1. Each Gateway can
handle three RLDS controllers, so if four
RLDS controllers are on the network, two
Gateways are needed. The first Gateway will
be address 1 and the RLDS units are numbered
as 1, 2, 3. The second Gateway will be
addressed as 4, but the RLDS is set to 1
because all units on the Gateway are numbered
sequentially 1 to 3. The RLDS controllers are
always numbered 1 to 3 when connected to the
Gateway.
To see a summary of RLDS controllers on the
network:
1. Press F5 for MORE.
2. Press L for Leak Detection.
3. The leak detectors are listed under
See Summary. Press the down arrow to
highlight a unit and press Enter to show the
summary of units listed.
The status screen for the selected RLDS controller is
shown.
4. F8 for ACTIONS.
5. Press B for Setup--you can name the RLDS in the
Name field.
6. Press the down arrow to the Num Channels field to
add the number of zones.
7. Press F10 to go back and see the current status of the
zones.
8. Press F9 HOME to go back to the Home screen.
