[] Glossary
ATSC
Acronym that stands for Advanced
Television Systems Committee and the
name of the digital broadcasting standards.
Aspect Ratio
The width of a TV screen relative to its
height. Conventional TVs are 4:3 (in other
words, theTV screen is almost square);
widescreen models are 16:9 (the TV screen
is almost twice as wide as its height).
Component Video
This isa video signal format that conveys
each of 3 principal colors of light (red, blue
and green) through different signal lines.This
allows the viewers to experience picture colors
as original as it is.There are several signal
formats, including Y/ Pb / Pr and Y / Cb / Cr.
Dolby Digital
The system developed by Dolby Laboratories
to compress digital sound. It offers stereo
sound (2ch) or multi-channel audio.
HDTV (high definition TV)
Ultimate digital format that produces high
resolution and high picture quality.
iii_iiii_i
NTSC
Acronym that stands for National Television
SystemsCommittee and the name of the
current analog broadcasting standards.
Password
A stored 4-digit number that allows access :
to parental control features.
SAP (secondary audio program)
Second-audiochannel delivered separately
from main-audio channel.Thisaudio channel is ......................................
usedasan alternate inbilingual broadcasting.
S-video
Offers higher quality images by delivering
each signal, color (c) and luminance (y)
independently of each other through
separate cables.
[] Cable Channel Designations
If yousubscribeto cableTV,the channelsaredisplayedas1-135.Cablecompaniesoftendesignatechannelswithlettersor letter-numbercombinations.
Pleasecheckwithyourlocalcablecompany.Thefollowingisa chartof commoncablechanneldesignations.
IV Display 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21
ITVD!spI_Y 43 44 45 46 _ 47 . 48 _ 49 _ 50 _ 51 52 53 54 55 56 57 58 59 60 61 62 63
w Display 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84
IVDisp!ay 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 1OO 101 102 103 104 105
_W+_ _ :_: _; w+_
_ _ _? --i- h-_-i-_ -_-_ _
iV Display 127 128 129 130 131 132 133 134 135
[] General Specifications
TV format: ATSC/ NTSC-MTVstandard
Closed caption system:
§15.122/FCC(digitalCC) §15.119/FCC(analogCC)
Channel coverage (ATSC/NTSC):
Terrestrial VHE: 2~13 UHE:14~69
CATV 2~13, A~W, W+1~W+94 (analogW+1~W+84),
A-5~A-1,5A
Tuning system: Channelfrequencysynthesizedtuning system
Channel access: Directaccesskeyboard,
Programmablescan,andup/d0wn
[] Electrical Specification
Sound output: 1W,80x2
•Designsandspecificationsaresubjecttochangewithout noticeand
withoutourlegalobligation.
•If thereisa discrepancybetweenlanguages,the defaultlanguagewill
beEnglish.
[] Other Specifications
Terminals:
Antennainput: VHF/UHF/CATV 750 unbalanced(F-type)
S-videoinput: Mini DIN4-pinjackx1 Y: 1Vp-p(750)
C:286mVp-p(750)
Videoinput: RCAjackx 1 1Vp-p(750)
Audioinput: RCAjackx4 2V rms
Componentvideoinput:
RCAjackx 3
PCinput: D-Sub15pinx1(RGB)
Y: 1Vp-p(750)
Pb:700mVp-p(750)
Pr:700mVp-p(750)
Minijack o3.5mm x 1 (audio)
Coaxialdigital audiooutput:
RCAjackxl 500mVp-p(750)
Headphone: 1/8inches (3.5mm)
Remote control: Digitalencodedinfraredlightsystem
Operating temperature:
41°F(5°C)to 104°F(40°C)
Power requirements:
120VAC+/- 10%,60Hz+/- 0.5%
Power consumption (maximum):
55W
LCD: 19incheswideXGApluspanel
Dimensions: <without stand> <with stand>
H:14.4inches(364mm) H:16.0inches(404.5mm)
W:19.3inches(490mm) W:19.3inches(490mm)
D:3.7inches (93mm) D:7.7inches (194.5mm)
Weight: 10.2Ibs. (4.6kg)
il............
il_:i!iii
! :!
