Switch Specifications
A-2 Specifications
Switch Specifications
Table A‐1providestheI/Oports,processorsandmemory,physical,andenvironmental
specificationsfortheC2G124‐24,C2G124‐48,andC2H124‐48.
Table A-1 Switch Specifications
Item Specification
C2G124-24
RJ45 ports 1 through 24 Twenty-four, 10BASE-T/100BASE-TX /1000BASE-T compliant
ports with auto-sensing and auto-negotiation via RJ45 UTP
connectors.
SFP ports 21 through 24 Four slots that support optional Mini-GBICs for 1000BASE-T
Gigabit copper and 1000BASE-FX fiber-optic connections.
When an SFP transceiver (Mini-GBIC) is installed in ports 21
through 24 establishes a link, the associated RJ45 fixed front
panel 10BASE-T/100BASE-TX /1000BASE-T port is disabled.
C2G124-48
RJ45ports 1 through 48 Forty-eight, 10BASE-T/100BASE-TX /1000BASE-T compliant
ports with auto-sensing and auto-negotiation via RJ45
connectors.
SFP ports 45 through 48 Four slots that support optional Mini-GBICs for 1000BASE-T
Gigerbit copper and 1000BASE-FX fiber-optic connections.
When an SFP transceiver (Mini-GBIC) is installed in ports 45
through 48 establishes a link, the associated fixed front panel
RJ45 10BASE-T/100BASE-TX /1000BASE-T port is disabled.
C2H124-48
RJ45ports 1 through 48 Forty-eight, 10BASE-T/100BASE-TX compliant ports with auto-
sensing and auto-negotiation via RJ45 connectors.
SFP ports 49 through 52 Four slots that support optional Mini-GBICs for 1000BASE-T
Gigabit copper and 1000BASE-FX fiber-optic connections. Unlike
the C2G124-24 and C2G124-48, all ports may be linked and
operating without affecting any RJ45 ports.
