Epiroc HM Series User Manual

Safety and operating instructions
© Construction Tools GmbH | 3390 5149 01 | 2020-09-22
Original Instructions
41
8 Troubleshooting
8.1 Control centre fault - reset
Cause Remedy By
For certain errors, it may be nec-
essary to perform a reset of the
system.
Switch off the carrier.
Wait until all LEDs on the display are off, but at least
45seconds.
The display is only fully de-energized after this time and
the reset can then be performed correctly.
Switch on the carrier again.
Carrier driver
8.2 LED 4 lights up: Interruption
Cause Remedy By
Electrical power supply of magnet
plate interrupted.
Turn off the carrier and secure it against being switched
on again (for example, by removing the ignition key and
keeping it safe).
let the connecting cable be replaced.
Workshop or Epiroc
Customer Center /
Dealer in your area
8.3 LED 4 flashes: Interruption of the connection between the control
center and the display
Cause Remedy By
Error at the interface between the
control center and the display.The
control center stops responding.
Perform a reset.
If the error persists after the reset:Turn off the carrier.
Contact the Epiroc Customer Center / Dealer in your area.
Carrier driver and
Epiroc Customer
Center / Dealer in
your area
8.4 LED 5 lights up: Overload
Cause Remedy By
The attached magnet plate is too
large for the system.
The built-in overload and fault
current limiter of the generator is
active.
Turn off the carrier and secure it against being switched
on again (for example, by removing the ignition key and
keeping it safe).
Contact the Epiroc Customer Center / Dealer in your area.
Carrier driver and
Epiroc Customer
Center / Dealer in
your area
The attached magnet plate is too
cold.
Note:If the magnet plate is very cold, it is possible that the
overload warning lights up on the display in the first few
operating minutes. However, this is only a warning, the
system is in safe operating condition.
Once the magnet plate is heated during cyclic switching,
the warning must go out after a certain time. This time can
take 5 up to 25 minutes depending on the magnet plate
type and operation mode.
In case of doubt consult the Epiroc Customer Center /
Dealer in your area.
Epiroc Customer
Center / Dealer in
your area
