Epson EB-X11 Service Manual

EB-S01/W01/X14G/S11/X11/S02/S02H/X02/W02/S12/S12H/X12/W12/X14 EH-TW480 Product Description CONFIDENTIAL
SEIKO EPSON 13 Revision C
1.3 Specifications
Model
EB-
S01
EB-
W01
EB-
X14G
EB-
S11
EB-
X11
EB-
S02
EB-
S02H
EB-
X02
EB-
W02
EB-
S12
EB-
S12H
EB-
X12
EB-
W12
EB-
X14
EH-
TW480
Item
Specification
of main part
LCD
Size
0.55 inch
(without
MLA)
0.59 inch
(with
MLA)
0.55 inch
(with
MLA)
0.55 inch (without MLA)
0.59 inch
(with
MLA)
0.55 inch
(without MLA)
0.59 inch
(with
MLA)
0.55 inch
(with
MLA)
0.59 inch
(with
MLA)
Pixel number
480,000
dots
(800 x
600) x 3
1,024,000
dots
(1280 x
800) x 3
786,432
dots
(1024 x
768) x 3
480,000
dots
(800 x
600) x 3
786,432
dots
(1024 x
768) x 3
480,000 dots
(800 x 600) x 3
786,432
dots
(1024 x
768) x 3
1,024,000
dots
(1280 x
800) x 3
480,000 dots
(800 x 600) x 3
786,432
dots
(1024 x
768) x 3
1,024,000
dots
(1280 x
800) x 3
786,432
dots
(1024 x
768) x 3
1,024,000
dots
(1280 x
800) x 3
Native resolution SVGA WXGA XGA SVGA XGA SVGA XGA WXGA SVGA XGA WXGA XGA WXGA
Aspect ratio 4:3 16:10 4:3 4:3 16:10 4:3 4:3 16:10 4:3 16:10
Projection
Lens
Focus Type Manual focus
Zoom
Type
Digital
Zoom
Manual optical zoom
Digital
Zoom
Manual
optical
zoom
Digital Zoom Manual optical zoom Digital Zoom Manual optical zoom
Ratio 1.0 - 1.35 1.0 - 1.2 1.0 - 1.35 1.0 - 1.2 1.0 - 1.35 1.0 - 1.2 1.0 - 1.35 1.0 - 1.2
Lamp
Type UHE (E-TORL)
Power consumption 200 W
Life
Normal
4000 H
Eco 5000 H
Brightness
Normal
mode
Color mode:
Dynamic,
Zoom: Wide
2600 lm 3000 lm 2600 lm 2600 lm 2800 lm 2800 lm 3000 lm 2800 lm
Eco mode 2080 lm 2400 lm 2080 lm 2080 lm 2240 lm 2240 lm 2400 lm 2240 lm
Sound output 2 W x 1 Monaural
1 W x 1
Monaural
2 W x 1 Monaural 1 W x 1 Monaural 2 W x 1 Monaural
HDMI terminal N/A x 1 N/A x 1
Network Function
Wired LAN N/A
Wireless LAN Unit N/A
USB terminal USB I/O
Type A x 1 (S02 is excluded)
Type B x 1
Operating Temperature
Temperature 5°C to 35°C
Humidity 20% to 80%

Epson EB-X11 Specifications

General

Matrix size	0.55 \
Projection distance	1.8 - 2.17 m
Projection technology	LCD
Contrast ratio (typical)	3000:1
Screen size compatibility	30 - 300 \
Projector native resolution	XGA (1024x768)
Keystone correction, horizontal	-30 - 30 °
Projector brightness (economic mode)	2080 ANSI lumens
Aspect ratio	4:3
RS-232 ports	1
Dimensions (WxDxH)	295 x 228 x 77 mm
Connectivity technology	Wired
F-number (relative aperture)	1.58
Focus	Manual
Offset	8:1 %
Throw ratio	1.48 - 1.77:1
Optical zoom	1.2 x
Focal length range	16.9 - 20.28 mm
Lamp type	UHE
Lamp power	200 W
Light source type	Lamp
Service life of light source	4000 h
Service life of light source (economic mode)	5000 h
DVI port	No
USB connector type	USB Type-A, USB Type-B
HDMI ports quantity	0
Serial interface type	RS-232
USB 2.0 ports quantity	2
Full HD	Yes
Supported video modes	1080i
Supported graphics resolutions	1024 x 768 (XGA), 1920 x 1080 (HD 1080)
RMS rated power	2 W
Image formats supported	BMP, GIF, JPG, PNG
Noise level	37 dB
Preset modes	Cinema, Dynamic, Presentation, sRGB
Country of origin	China
Noise level (economic mode)	29 dB
Product type	Standard throw projector
Product color	White
Cable lock slot type	Kensington
Power consumption (standby)	0.47 W
Power consumption (typical)	270 W
Pallet width	800 mm
Pallet height	2178 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	78 pc(s)
Quantity per pallet layer	6 pc(s)

Weight and Dimensions

Depth	228 mm
Width	295 mm
Height	77 mm
Weight	2300 g
Package depth	358 mm
Package width	357 mm
Package height	156 mm
Package weight	3500 g
