Epson EB-X11 Service Manual

EB-S01/W01/X14G/S11/X11/S02/S02H/X02/W02/S12/S12H/X12/W12/X14 EH-TW480 Appendix CONFIDENTIAL
SEIKO EPSON 142 Revision C
 3rd page or later
The error log of the ballast is displayed.
The last 7 error logs are displayed (the latest on top). None is displayed if there’s
no error.
5.1.3 Initializing (Resetting) the AS Menu Values
The operational procedures and the values of initialization of the AS Menu are shown
below.
No. Item No. Item
1 Status of ballast error 4 Type of error
2 Page number of ballast error log
5 Acquired data of TEMP? command
3 Log on ballast error
PB Log 1:
ERR LOG CD TEMP
03041032 FFFF14FF LF F0E1D2C3
B4A59687 0F
(1) (2) (3) (4) (5)
Type
Clearing the Lamp
Information
Clearing the AS
Information
Clearing the Log
Information
Operation
Press [ ] and
[Source Search] on
the projector for 10
sec. during display-
ing the menu.
Press [ ] and
[Source Search] on
the projector for 10
sec. during display-
ing the menu.
Press [Right] either
on the projector or
the controller for
more than 5 sec.,
then within 3 sec.
press [Enter] for 2
sec. during display-
ing the menu.
Item
Total Operation
Time
Maintained Reset to 0 N/A
Lamp Operation
Time (C/H/M/L)
Reset to 0 Reset to 0 N/A
Lamp ON Reset to 1 Reset to 1 N/A
Lamp OFF Reset to 0 Reset to 0 N/A
Lamp Replacement
Add 1 to the
current value
Reset to 0 N/A
Error Log N/A N/A
Spacing
(Initialized to the sta-
tus of acquiring
none)
Error Count N/A N/A Reset to 0
Control N/A N/A N/A
PB Error Log N/A N/A
Spacing
(Initialized to the sta-
tus of acquiring
none)

Epson EB-X11 Specifications

General

Matrix size	0.55 \
Projection distance	1.8 - 2.17 m
Projection technology	LCD
Contrast ratio (typical)	3000:1
Screen size compatibility	30 - 300 \
Projector native resolution	XGA (1024x768)
Keystone correction, horizontal	-30 - 30 °
Projector brightness (economic mode)	2080 ANSI lumens
Aspect ratio	4:3
RS-232 ports	1
Dimensions (WxDxH)	295 x 228 x 77 mm
Connectivity technology	Wired
F-number (relative aperture)	1.58
Focus	Manual
Offset	8:1 %
Throw ratio	1.48 - 1.77:1
Optical zoom	1.2 x
Focal length range	16.9 - 20.28 mm
Lamp type	UHE
Lamp power	200 W
Light source type	Lamp
Service life of light source	4000 h
Service life of light source (economic mode)	5000 h
DVI port	No
USB connector type	USB Type-A, USB Type-B
HDMI ports quantity	0
Serial interface type	RS-232
USB 2.0 ports quantity	2
Full HD	Yes
Supported video modes	1080i
Supported graphics resolutions	1024 x 768 (XGA), 1920 x 1080 (HD 1080)
RMS rated power	2 W
Image formats supported	BMP, GIF, JPG, PNG
Noise level	37 dB
Preset modes	Cinema, Dynamic, Presentation, sRGB
Country of origin	China
Noise level (economic mode)	29 dB
Product type	Standard throw projector
Product color	White
Cable lock slot type	Kensington
Power consumption (standby)	0.47 W
Power consumption (typical)	270 W
Pallet width	800 mm
Pallet height	2178 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	78 pc(s)
Quantity per pallet layer	6 pc(s)

Weight and Dimensions

Depth	228 mm
Width	295 mm
Height	77 mm
Weight	2300 g
Package depth	358 mm
Package width	357 mm
Package height	156 mm
Package weight	3500 g
