Useful Functions
59
Using the HDMI Link Function
HDMI Link Function
When an AV device that meets the HDMI CEC standards is connected to the projector's HDMI port, you can
perform linked operations such as linked power on and volume adjustment for the AV system from one
remote control. Also, when projecting images in WirelessHD, you can use the HDMI link function (EH-
TW6100W only).
c
•
As long as the AV device meets the HDMI CEC standards, you can use the HDMI link function even if
the AV system in-between does not meet the HDMI CEC standards.
•
Up to 3 multi-media players that meet the HDMI CEC standards can be connected at the same time.
Connection Example
Projector Amplifier Multi-media players and so on
HDMI Link Settings
By pressing the button on the remote control, and
setting HDMI Link to On, you can operate the following
functions.
Function Explanation
Power On Link Powers on the projector when content is played back on the connected device. Or,
powers on the connected device when the projector is turned on.
Power Off Link Powers off the connected device when the projector is turned off.
•
This only works when the connected device's CEC power link function is enabled.
•
Note that depending on the status of the connected device (for example, if it is record-
ing), the device may not power off.
Audio Out Device When an AV system is connected, you can set whether to output audio from the pro-
jector's speaker, or from the AV system's speaker.
Input Change Link Changes the input source of the projector to HDMI when content is played back on the
connected device.
Connected Devices
Operations
You can perform operations such as Play, Stop, Fast Forward, Rewind, Next Chapter,
Previous Chapter, and Pause from the remote control for the projector.
c
•
To use the HDMI Link function, you must configure the connected device. See the documentation
supplied with the connected device for more information.
•
Even when using the WirelessHD Transmitter with Power On Link set to Device -> PJ or
Bidirectional, if WirelessHD is set to On, this projector also turns on when the AV device connected
to the WirelessHD Transmitter is turned on (EH-TW6100W only).
s Settings-HDMI Link-Power On
Link p.71

Epson EH-TW6100W Specifications

General

Aspect ratio	16:9
RS-232 ports	1
Matrix size	0.61 \
White light output	2300 ANSI lumens
Projection distance	- m
Projection technology	3LCD
Screen size compatibility	30 - 300 \
Projection distance (tele)	1.4 - 14.5 m
Projection distance (wide)	0.9 - 8.9 m
Projector native resolution	1080p (1920x1080)
Keystone correction, horizontal	-30 - 30 °
Full HD	Yes
Color modes (2D)	Dynamic, Cinema
Supported 3D formats	Side by side, Top and bottom, Frame packing
Analog signal format system	-
Focus	Manual
Focal length range	18 - 29 mm
Aperture range (F-F)	1.51 - 1.99
Lamp type	E-TORL
Lamp power	230 W
Light source type	Lamp
Service life of light source	4000 h
Service life of light source (economic mode)	5000 h
DVI port	No
USB connector type	USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	0
Noise level	32 dB
Country of origin	China
2D/3D frequency image	240/480 Hz
Noise level (economic mode)	24 dB
RMS rated power	20 W
Placement	Desktop
Product type	Standard throw projector
Product color	White
Market positioning	Home cinema
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.35 W
Power consumption (typical)	358 W
Power consumption (economy mode)	274 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Cables included	AC, HDMI
Pallet width	800 mm
Pallet height	2010 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	12 pc(s)
Quantity per pallet (UK)	24 pc(s)
Quantity per pallet layer	2 pc(s)
Quantity per pallet layer (UK)	4 pc(s)

Weight and Dimensions

Depth	365 mm
Width	420 mm
Height	137 mm
Weight	6000 g
Package depth	495 mm
Package width	435 mm
Package height	310 mm
Package weight	9720 g
