Epson EH-TW6100W User Manual

Troubleshooting
80
Problem Page
Problems with USB storage
devices
Slideshow does not start p.87
Other problems No audio, or the audio is too low. p.87
*
Because color reproduction differs between monitors and computer LCD screens, the image projected by the
projector and the color tones displayed on the monitor may not match, however this is not a fault.
Problems relating to images
No images appear
Check Remedy
Is the projector turned on?
Press the
button on the remote control or the button
on the control panel.
Is the power cable connected? Connect the power cable.
Are the indicators switched off? Disconnect and then reconnect the projector's power cable.
Check that power is being supplied.
Is an image signal being input?
Check that the connected device is turned on. When Messag-
es is set to On from the configuration menu, image signal mes-
sages are displayed.
s Extended - Display - Messages p.73
Is the image signal format setting correct? When Video is input
If nothing is projected even when Video Signal is set to Auto
from the configuration menu, set the signal that matches the
connected device.
s Extended - Input Signal - Video Sig-
nal p.73
When Component is input
If nothing is projected even when Component is set to Auto
from the configuration menu, set the signal that matches the
connected device.
s Extended - Input Signal - Compo-
nent p.73
Are the configuration menu settings correct?
Reset all of the settings.
s Reset - Reset All p.75
(Only when projecting computer image sig-
nals)
Was the connection made while the power of
the projector or the computer was already
turned on?
If the connection is made while the power is already turned on,
the key (Function key and so on) that changes the computer's
image signal to external output may not work. Turn off the power
for the computer and the projector and then turn it back on
again.
Moving images are not displayed
Check Remedy
(Only when projecting computer image sig-
nals)
Is the computer's image signal set to external
output and to output to the LCD monitor at
the same time?
Depending on the computer's specifications, moving images
may not be displayed when the computer is set to external out-
put and to the LCD monitor output at the same time.
Change it so that the image signal is set to external output only.
For the computer's specifications, see the documentation sup-
plied with the computer.

Epson EH-TW6100W Specifications

General

Aspect ratio	16:9
RS-232 ports	1
Matrix size	0.61 \
White light output	2300 ANSI lumens
Projection distance	- m
Projection technology	3LCD
Screen size compatibility	30 - 300 \
Projection distance (tele)	1.4 - 14.5 m
Projection distance (wide)	0.9 - 8.9 m
Projector native resolution	1080p (1920x1080)
Keystone correction, horizontal	-30 - 30 °
Full HD	Yes
Color modes (2D)	Dynamic, Cinema
Supported 3D formats	Side by side, Top and bottom, Frame packing
Analog signal format system	-
Focus	Manual
Focal length range	18 - 29 mm
Aperture range (F-F)	1.51 - 1.99
Lamp type	E-TORL
Lamp power	230 W
Light source type	Lamp
Service life of light source	4000 h
Service life of light source (economic mode)	5000 h
DVI port	No
USB connector type	USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	0
Noise level	32 dB
Country of origin	China
2D/3D frequency image	240/480 Hz
Noise level (economic mode)	24 dB
RMS rated power	20 W
Placement	Desktop
Product type	Standard throw projector
Product color	White
Market positioning	Home cinema
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.35 W
Power consumption (typical)	358 W
Power consumption (economy mode)	274 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Cables included	AC, HDMI
Pallet width	800 mm
Pallet height	2010 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	12 pc(s)
Quantity per pallet (UK)	24 pc(s)
Quantity per pallet layer	2 pc(s)
Quantity per pallet layer (UK)	4 pc(s)

Weight and Dimensions

Depth	365 mm
Width	420 mm
Height	137 mm
Weight	6000 g
Package depth	495 mm
Package width	435 mm
Package height	310 mm
Package weight	9720 g
