Epson EH-TW6100W User Manual

Configuration Menu
74
Function Menu/Settings Explanation
Display
Menu Position - Sets the position where the menu should be dis-
played.
Menu Color Color 1, Color 2 Selects the color for the top menu.
•
Color 1: Black
•
Color 2: Blue
Messages On, Off Sets whether or not to display the following mes-
sages (On or Off).
•
Item names for image signals, color modes, as-
pect ratios, and loading memory.
•
If the internal temperature is rising when no im-
age signal is being input or an unsupported sig-
nal is detected.
Display Background Black, Blue, Logo Selects the screen status when no image signal
is being input.
Startup Screen On, Off Sets whether or not to show a startup screen
when projection begins (On or Off). If changed,
this setting is enabled after you power off the
projector and the cool-down process is com-
plete.
Standby Confirma-
tion
On, Off Sets whether or not to display a standby confir-
mation message (On or Off).
s p.23
Input Signal
Video Signal Auto, NTSC,
NTSC4.43, PAL, M-
PAL, N-PAL, PAL60,
SECAM
Sets the signal type depending on the video de-
vice connected to the Video port. When set to
Auto, the video signal is set automatically.
If you notice noise in the image even when set to
Auto, or if you are not seeing any image at all,
select the correct signal type from the available
options.
Component Auto, YCbCr, YPbPr Sets the output signal for the video device con-
nected to the Component port.
When set to Auto, the output signal is set auto-
matically. If you notice unnatural colors when set
to Auto, set the appropriate output signal from
the available options.
Language
- Selects the display language.
Reset
Yes, No
Resets all adjustment values for Extended to
their default settings.
Memory menu
Function Explanation
Load Memory
Loads settings saved using the Save Memory function.s p.40
This cannot be selected if you have not saved any settings with the Save Mem-
ory function.
Save Memory
Saves certain Image and Signal settings to memory. s p.39
Erase Memory
Erases settings saved to memory that you no longer need. s p.40
Rename Memory
Renames a saved memory. s p.40

Epson EH-TW6100W Specifications

General

Aspect ratio	16:9
RS-232 ports	1
Matrix size	0.61 \
White light output	2300 ANSI lumens
Projection distance	- m
Projection technology	3LCD
Screen size compatibility	30 - 300 \
Projection distance (tele)	1.4 - 14.5 m
Projection distance (wide)	0.9 - 8.9 m
Projector native resolution	1080p (1920x1080)
Keystone correction, horizontal	-30 - 30 °
Full HD	Yes
Color modes (2D)	Dynamic, Cinema
Supported 3D formats	Side by side, Top and bottom, Frame packing
Analog signal format system	-
Focus	Manual
Focal length range	18 - 29 mm
Aperture range (F-F)	1.51 - 1.99
Lamp type	E-TORL
Lamp power	230 W
Light source type	Lamp
Service life of light source	4000 h
Service life of light source (economic mode)	5000 h
DVI port	No
USB connector type	USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	0
Noise level	32 dB
Country of origin	China
2D/3D frequency image	240/480 Hz
Noise level (economic mode)	24 dB
RMS rated power	20 W
Placement	Desktop
Product type	Standard throw projector
Product color	White
Market positioning	Home cinema
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.35 W
Power consumption (typical)	358 W
Power consumption (economy mode)	274 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Cables included	AC, HDMI
Pallet width	800 mm
Pallet height	2010 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	12 pc(s)
Quantity per pallet (UK)	24 pc(s)
Quantity per pallet layer	2 pc(s)
Quantity per pallet layer (UK)	4 pc(s)

Weight and Dimensions

Depth	365 mm
Width	420 mm
Height	137 mm
Weight	6000 g
Package depth	495 mm
Package width	435 mm
Package height	310 mm
Package weight	9720 g
