Troubleshooting
120
When the Paper Jams
This section explains how to remove paper jammed inside the printer.
The procedure differs for the front roll paper feeder and the rear roll paper feeder. Check the Operation panel to
determine which unit is jammed.
Light Displays Explanation
Paper is jammed in the paper feed path for the front roll paper feeder.
(Only the Dual Roll Model supports front roll paper.)
Paper is jammed in the paper feed path for the rear roll paper feeder.
Tip:
See the following if the table above and the lamp status differs.
U “Warning Buzzer and Light Displays” on page 108
!
Caution:
O When removing jammed paper, do not remove it too forcibly. Also, do not work with an unstable posture.
If the paper is suddenly pulled out, an injury could occur due to unnecessary force.
O Do not leave the printer with paper jammed inside.
Smoke could be emitted or it could ignite and cause a fire.
To Next Page
