18
Control Panel
FEED button
Pressing this button once feeds the roll paper by one line. Holding this button down feeds the
roll paper continuously.
LED
PAPER OUT LED
•Lights when there is no more roll paper or there is little remaining.
•Off when there is a sufficient amount of roll paper remaining.
•Flashes when a self-test is in progress.
ERROR LED
Lights or flashes when the printer is offline.
•Lights after the power is turned on or after a reset (offline). Automatically goes out after a
while to indicate that the printer is ready.
•Lights when the end of t he roll paper is detected, and when printing has stopped (offline). If
thi
s happens, replace the roll paper.
•Flashes when an error occurs. (For details about the flash codes, see "Error Status" on page 21.)
•Goes out during regular operation (online).
POWER LED (green)
•Lights when the power supply is on.
•Goes out when the power supply is turned off.
