Epson TM-T70-i Technical Reference Guide

Chapter 1 Product Overview
25
1
Product Specifications
* When the optional wireless LAN cable set (OT-WL01) is used.
Printing method Thermal line printing
Cutting method Partial cut (cutting with one point in left edge left uncut)
Roll paper (single-ply) Width: 79.5 ± 0.5 mm (3.13 ± 0.02")
Interface Ethernet (10BASE-T/100BASE-TX)
Wireless LAN (IEEE802.11b/g/n)*
Buffer Receive buffer 4 KB/45 bytes (selectable using the DIP switch 1-2)
Downloaded buffer 12 KB (both for user-defined characters and downloaded images)
NV graphics data 256 KB
Barcode/two-dimensional
code printing
UPC-A, UPC-E
JAN 8 (EAN 8), JAN 13 (EAN 13)
CODE 39
ITF
CODABAR (NW-7)
CODE 93
CODE 128
PDF417
QR CODE
Power supply EPSON AC ADAPTER, RA (Model: M266A)
Life Mechanism 15,000,000 lines
Thermal head 100 million pulses, 100 km
Autocutter 1,500,000 cuts
MTBF 360,000 hours
MCBF 52,000,000 lines
Temperature/humidity Operating: 5 to 45°C {41 to 113°F}, 10 to 90% RH
Storage: -10 to 50°C {14 to 122°F}, 10 to 90% RH
Overall dimensions 114 × 125 × 194 mm {4.49 × 4.92 × 7.64"} (H × W × D)
Weight (mass) Approx. 1.8 kg {3.96 lb} (Roll paper excluded)

Epson TM-T70-i Specifications

General

Type	POS printer
Character size	1.69 x 3.38 mm
Print technology	Thermal
Wi-Fi	No
Ethernet LAN	Yes
Ethernet LAN data rates	10, 100 Mbit/s
USB connector	Micro-USB, USB Type-A
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Connectivity technology	Wired
Mean cycles between failures (MCBF)	52000000
Internal memory	256 MB
Autocutter durability	1.5 million cuts
Mean time between failures (MTBF)	360000 h
Voltage	24 V
Product color	Black

Weight and Dimensions

Depth	194 mm
Width	125 mm
Height	114 mm
