Chapter 2 Setup
2
Changing the Paper Width
The TM-U220-i accommodates 76 mm {3"},69.5 mm {2.74"}, 57.5 mm {2.26"} wide paper rolls.
Follow the steps below to change the paper width.
When changing the paper width, be sure to make the setting for the paper width with the
memory switch. (U
"Setting the Memory Switches" on page 62)
When you use a near-end detector equipped model, be sure not to pinch the lead wires of
the near-end detector between the roll paper guide and the roll paper holder, and to push the
lead wires inside so that the lead wire of the paper-end detector does not contact the motor
gear.
Leading the wires between
the holder and frame
Roll paper guide
Roll paper holder
To Next Page
