ESAB Caddy Tig 2200i AC/DC Service Manual

S0740 800 179/E071123/P64
-- 6 2 --
ct33i
FAULT--TRACING
Try these recommended checks and inspections before sending for an authorised service
technician.
Type of fault Corrective action
No arc. S Check that the mains power supply switch is turned on.
S Check that the welding current supply and return cables are
correctly connected.
S Check that the correct current value is set.
S Check the mains power supply.
The welding current is
interrupted during welding.
S Check to see whether the thermal cut--outs have tripped.
S Check the mains power supply fuses.
The thermal cut--out trips
frequently.
S Make sure that you are not exceeding the rated data for the
welding power source (i.e. that the unit is not being
overloaded).
Poor welding performance. S Check that the welding current supply and return cables are
correctly connected.
S Check that the correct current value is set.
S Check that the correct electrodes are being used.
S Check the gas flow.
SPARE PARTS
The spare parts list is published in a separate document that can be downloaded from the
internet: www.esab.com
Product Filename
T ig 2200i AC/DC 0459 839 013
TA33, TA34 0459 839 014
NOTES

ESAB Caddy Tig 2200i AC/DC Specifications

General

AC Frequency	20 - 250 Hz
Dimensions	418 x 188 x 345 mm
Weight	15 kg
Protection Class	IP23
Frequency	50/60 Hz
Duty Cycle (TIG DC, 220A)	25%
Duty Cycle (TIG AC, 220A)	25%
Input Voltage	230 V
Current Range (TIG AC/DC)	220 A
