5. SCOTOPIC PUPIL SIZE (SPS) - MEASUREMENT FUNCTION
This function is to measure the pupil size of the subject eye in the dark.
Switch to the SPS measurement by pressing the measurement mode switch on the front panel.
When measuring the scotopic pupil size, darken the room.
Indication of SPS measurement mode
<To print out the measurement results of SPS, R/K, REF and KRT at the same time>
The measurement results of SPS, R/K, REF and KRT can be printed out at the same time by
pressing the print button after the measurement of SPS when switching to SPS measurement mode
without printing out their measurement result with the setting of Auto Print “Off”.
Example of printout Example of data screen output
To Next Page
