Contact your local distributor about operation, connection method and output data etc.
The instruments which are connected to this device by RS-232C should comply with the safety
standard of IEC60601-1.
Do not touch the external connection terminal and examinee at the same time. It may cause
electric shock.
Select the baud rate of RS-232C from below.
Selectable baud rate Setting before shipment
115200 bps ○
38400 bps
9600 bps
In case of RS-232C, CHARACTER (data bit count), PARITY (check of transfer data) and STOP BIT
(exit code) are set as CHARACTER (8), PARITY (NONE) and STOP BIT (1) and cannot be changed.
9. DATA SCREEN FUNCTION
The measurement results can be displayed on the screen and checked by using the data screen function.
In case of displaying measurement results
1. Set “Data Screen” on the Setup screen as “On”.
In case that the setting of “Data Screen” is “On”, the measurement data of the right eye is
displayed regardless of the settings of “Print REF/ KRT”.
To Next Page
