4 Installing Your Switch
Safety Considerations for Installing Switches
What You Will Need for the Installation
Attaching the Switch to a Rack
Installing Optional Components
Installing Internal Power Supplies
Turn on the Switch
Connecting Network Interface Cables
Before you attempt to install or remove an Extreme Networks switch, read the precautions in Safety
Considerations for Installing Switches on page 32.
Extreme Networks switches fit into standard 19-inch equipment racks.
A four-post rack-mounting kit is provided with the switch. A two-post kit can be ordered separately.
The installation process includes the following tasks:
1 Prepare to install the switch.
See What You Will Need for the Installation on page 32.
2 Install the switch in the rack.
See Attaching the Switch to a Two-Post Rack on page 39.
3 Install optional components: optical transceivers and cables.
See the instructions in Installing Optional Components on page 44.
4 If your switch does not come with an installed internal power supply, install one or two power
supplies.
See Installing Internal Power Supplies on page 45.
Note
Be aware of whether the power supply you are installing is AC-powered or a DC-powered.
The installation instructions are dierent depending upon what type of power is used.
5 Power up the switch.
See Turn on the Switch on page 52.
6 Connect network interface cables.
See Connecting Network Interface Cables on page 52.
7 Perform initial network connection and configuration.
See Activating and Verifying the Switch on page 54.
VSP 7400 Series Switches: Hardware Installation Guide 31
