A Technical Specifications
VSP 7400 Series Switches Technical Specifications
750 W Power Supplies Technical Specifications
Power Cord Requirements for AC-Powered Switches and AC Power Supplies
This section lists technical specifications for the hardware products described in this document.
VSP 7400 Series Switches Technical Specifications
The ExtremeSwitching VSP 7400 Series includes the following switches:
•
VSP 7432CQ (base model)
•
VSP 7432CQ-F (includes two AC power supplies; front-to-back airflow)
•
VSP 7432CQ-R (includes two AC power supplies; back-to-front airflow)
•
VSP 7400-48Y (base model)
•
VSP 7400-48Y-F (includes two power supplies; front-to-back airflow)
•
VSP 7400-48Y-R (includes two power supplies: back-to-front airflow)
Specifications for supported power supplies, including dimensions and weights, are found in 750 W
Power Supplies Technical Specifications on page 72.
Table 17: VSP 7400 Unpackaged Dimensions
VSP 7432CQ switch Height: 4.34 cm (1.71 in)
Width: 43.96 cm (17.31 in)
Length: 53.95 cm (21.24 in)
VSP 7400-48Y switch Height: 4.34 cm (1.71 in)
Width: 43.96 cm (17.31 in)
Length: 53.95 cm (21.24 in)
Fan unit, front-to-back or back-to-front Height: 4.0 cm (1.57 in)
Width: 4.0 cm (1.57 in)
Length: 13.4 cm (5.28 in)
Four-post rack mount kit (included with switch) Height: 2.1 cm (0.83 in)
Width: 4.4 cm (17.3 in)
Length: 63.0 cm - 90.0 cm (24.80 in - 35.43
in)
Two-post rack mount kit (separately orderable) Height: 4.2 cm (1.65 in)
Width: 2.4 cm (0.93 in)
Length: 12.5 cm (4.92 in)
VSP 7400 Series Switches: Hardware Installation Guide 65
