Extreme Networks ExtremeSwitching VSP 7400 Series User Manual

7 Monitoring the Switch
VSP 7400 Series Switch LEDs
750 W AC Power Supply LEDs
750 W DC Power Supply LEDs
The following topics help you monitor the status of the switch/appliance as it is running.
VSP 7400 Series Switch LEDs
The following tables describe the meanings of the LEDs on the front panel of the VSP 7400 Series
switch:
•
VSP 7432CQ LEDs for Data Ports (1-32) on page 61
•
Table 10 on page 62
•
Table 11 on page 62
•
VSP 7400 Series Front Panel System LEDs on page 62
•
Table 13 on page 63
VSP 7432CQ LEDs for Data Ports (1-32)
Table 9: LEDs for Data Ports (1-32)
Port Configuration Color/State Meaning
100 Gb
or 4x25 Gb
Steady green Port OK
Blinking green Port transmitting or receiving
Slow blinking green Port disabled by software
O No link/Fault
40 Gb
or 4x10 Gb
Steady green Port OK
Blinking green Port transmitting or receiving
Slow blinking green Port disabled by software
O No link/Fault
VSP 7400-48Y LEDs for Data Ports (1-54)
Note
Data Ports 55 and 56 are reserved.
VSP 7400 Series Switches: Hardware Installation Guide 61
