AMPLIFICADOR ADS/VDS
ADS/VDS AMPLIFIER
AMPLIFICATEUR ADS/VDS
ADS/VDS VERSTÄRKER
MIC
EXITEXIT
JP3
JP2
PACK EXTENSION
CN1
CN2
LEDS ON
SLAVE
MASTER
LEDS OFF
TARJETERO
CARD HOLDER
AUDIO
PROG
C
NO
NC
VERSION :
LANGUAGE
IDIOMA
10
PAN & TILT
D
C
B
A
JP3 JP2
CN3
SW1
CN1
CN2
MIC
JP4
JP4
CT OUT CT IN
L
+
-
M
V
+12
C
NcNo
-
BS
S
CT
18V
DC
ALIMENTACION
POWER SUPPLY
18 Vdc
-+
CN7 VIDEO TEST MONITOR
CN2: “L+, L-”: Button and card holder illumination connection. Door Controller Common Button Wire
2
CN1: Connection for call extension module, keypad, display or up to three buttons (the same amplifier for buildings
and kits with up to 3 lines).
1
3
Configuration Switches:
JP2 : Main/Secondary Panel Selection Switch
JP3: Camera LEDs (video amplifier)
JP4: CT: Camera activation/auxiliary output
Secondary Panel
Leds OFF
CT: entrance.
Connect 12 Vdc to activate
camera + leds permanently
Main Panel
Leds ON
CT: 11 Vdc output
5
CN3: Status LED connection. Very useful for disabled people, allowing leds to be connected which provide
information on communication status.
Depending on the action executed, the corresponding LED is activated):
6
CN7. Video Test Monitor: Monitor Programming and Test Connector
4
Remote camera with 10º Pan&Tilt adjustment function
( video amplifier).
VDS Amplifier - New Cityline Panels
L2, +: Call LED
L3, +: Communication LED
L4, +: Door lock-release LED
L1
L2
L3
L4
+
L2, L3, L4: give a negative result when the corresponding action is executed, thus activating the LED connected
between Lx and +.
L4
The VDS amplifier manages all the VDS system functions: calls, two-way communication, door opening, programming....
It is available in Audio and Video versions.
12
1
3
2
4
5
6
7
8
11
7
Voice synthesiser: ‘Door open’ language selection.
L
10
9
CN1
Iluminación
GND
1
2
3
Vcc
CN1 Detail:
