Pin 3 Orange/Black - 2nd Unlock 250mA negative (-) output: This is an optional output that will provide
a (-) pulse for driver’s priority door lock. IMPORTANT: You must isolate the driver’s door and set
feature 1-03 to option 2 (on).
Pin 4 Blue - Unlock 250mA negative (-) output: This is an optional output that will provide a (-) pulse for
unlocking doors. System will unlock doors and disarm alarm. IMPORTANT: You must reverse polarity
for (+) trigger door lock systems. For additional lock settings review Option Group 1.
Pin 5 Blue/Black - Lock 250mA (-) negative output: This is an optional output that will provide a (-) pulse
for locking doors. System will lock doors and arm alarm. IMPORTANT: You must reverse polarity for
(+) trigger door lock systems. For additional lock settings review Option Group 1. Pin 6 not used.
Pin 6 None - B- ground output: available when using a Firstech door lock Module FT-DM600, FT-DM700
Connector 12 (CN12), 2-Pin (Pre-wired LED) **WHITE connector Note: Do not mistake for
Thermistor port. Note: The LED will stay solid blue when armed for the duration of the
sensor set up time. (Approx. 25 seconds)
Pin 1 Black - L.E.D negative (-) ground.
Pin 2 Black/White- L.E.D. 2.5V positive (+) output.
Connector 13 (CN13), 4-Pin (Pre-wired RPS Touch or RPS 2)
Pin 1 Black - Negative (-) ground.
Pin 2 White - Negative (-) paging input.
Pin 3 Red - 12V positive (+) output.
Pin 4 Yellow - 9V positive (+) L.E.D. output.
Connector 14 (CN14), 4-Pin (Pre-wired DAS Sensor)
Pin 1 Black - Negative (-) ground when armed (GWA).
Pin 2 White - 2nd stage negative (-) input. (Instant trigger)
Pin 3 Red - 12V positive (+) output.
Pin 4 Yellow - 1st stage negative (-) input. (Warn away)
