4-02 Aux 2 Output: This feature determines the duration of the auxiliary 2 output. (Option 4 allows the
output duration to be set for a specific length of time 1-99 sec. and 1-15 min (with OP500 update only)
only available when using the OP500)
FO1 - 500mS: This option will provide a (-) negative output for 500 milliseconds (0.5 seconds)
output on any POC programmed with setting 11 (AUX 2)
FO2 - Latched: This option will provide a latched (-) negative output on any POC programmed with
setting 11 (AUX 2). Note: This latched output will reset when ignition is turned on.
FO3 - 500mS pulse + programmable timed output: this option will provide a (-) negative
output for 500 milliseconds (0.5 seconds) output on any POC programmed with setting 11 (AUX
2). It will pause for 250 milliseconds then provide a timed output (based off of feature 4-02 option
4). Note: in order to program the timed output the user must change feature 4-02 to option 4, then
adjust AU2 (AUX programmable output time) to desired time. To complete the programming steps
feature 4-01 must be changed to option 3. (i.e. half second pulse…pause…10 second pulse) This
option can be used to roll windows up or down on a vehicle that requires a similar
action using the driver’s door key cylinder.
FO4 - Program: This option allows the AUX output time to be programmed for a duration
between 1-99 seconds. Note: The OP500 must be updated for additional time duration
settings. (1-15 minutes available)
4-03 Aux 1 Output Control: This feature allows the user to configure the method of which Auxiliary 1
can be activated.
FO1 - Remote: (default) This option allows AUX 1 (output time based on feature 4-01) to be
triggered by any 4 button Firstech remote or drone.
FO2 - With Arm: this option will trigger AUX 1 (output time based on feature 4-01) any time the
CM7 is locked/armed the first time (i.e. if you send a second lock/arm command it will not trigger
again)
FO3 - With Disarm: this option will trigger AUX 1 (output time based on feature 4-01) any time
the CM7 is unlocked/disarmed. Note: the system has to be in the armed state when
disarming in order to trigger AUX 1. (I.e. if the vehicle is already in the unlocked/
disarmed state and you send a second unlock/disarm command it will not trigger the
output)
FO4 - With ignition removed: this option will trigger AUX 1 (output time based on feature
4-01) as soon as Ignition input is removed from the CM7. (I.e. this feature can be used with a
manual transmission vehicle to open the door input circuit on the CM7 for a set period of time when
reservation mode is complete in order to prevent the dome light from cancelling reservation mode.)
4-04 Aux 2 Output Control: This feature allows the user to configure the method of which Auxiliary 2 can
be activated.
FO1 - Remote: (default) this option allows AUX 2 (output time based on feature 4-02) to be
triggered by any 4 button Firstech remote or drone.
FO2 - With Arm: this option will trigger AUX 2 (output time based on feature 4-02) any time the
CM7 is locked/armed the first time (I.e. if you send a second lock/arm command it will not trigger
again)
Copyright 2014 Firstech, LLC. Page 2Copyright 2014 Firstech, LLC. Page 2
CM7200 Master Guide
Starter System
techfeed.compustar.com
Copyright 2014 Firstech, LLC. Page 42
