CM7200 Master Guide

Starter System

techfeed.compustar.com

Alarm LED Diagnostics

When the alarm is triggered the LED on the RPS (if installed), Secure Valet (if installed) and the LED (if

installed) will flash a certain amount of times as shown in the table below. This is intended for users with 1

Way remotes.

Priority Trigger LED Flash Diagnostic

1 Door/Hood/Trunk/Ign Triggered 2 flashes, break, then repeat

2 2nd Shock Triggered 3 flashes, break, then repeat

3 2nd Auxiliary Input Triggered 4 flashes, break, then repeat

4 Panic with remote 5 flashes, break, then repeat

Number of

Parking Light

Flashes

Remote Start Shutdown Error

1 Lost engine sensing signal (Tach/Alternator/Tachless)

2 Lost emergency brake signal (Manual Transmission)

3 Foot brake triggered

4 Hood pin triggered

I have everything hooked up and the system will not respond.

A: The remotes need to be programmed. Review the “Common Procedure” section of this manual.

When remote starting, the siren chirps 3 times and parking lights flash 3 then 1 time.

A: You must program tach before remote starting. Also be sure to check the foot brake and ignition wires on

the CM7000 and CM7200.

I am trying to program the control module with the OP500 Option Programmer and it flashes

“ER 01” when I plug it in to the antenna cable. What should I do?

A: Make sure that the system is not locked/armed. The last thing to check is the antenna cable or antenna

extension cable – make sure this is not damaged. If you need to, try another cable. When the OP500

is working properly, it will read “success good.” You no longer need to program the remotes before the

OP500 will sync.

What is the green/white wire loop inside the brain module?

A: This wire determines the transmission mode. With the loop intact, the system is set for manual

transmissions. With the loop cut, the system is set for automatic transmission.

What do I do with the thick blue wire on Connector 1?

A: It is used to power a (+) 2nd Ignition. You can also change the output via jumper within the control module. It can

be changed to power a (+) 2nd Accessory or (+) Parking light wire.
