427-0032-00-12 Version 170 Mar 2014 1-11
1 PT-Series Camera Installation
1.9 PT-Series Camera Specifications
Power consumption is independent of the input voltage when the heater is off. The power drawn by
the heaters increases with the input voltage to a maximum at 30 Volts.
THERMAL CAMERA SPECS
Detector Type Long-Life, Uncooled
VO× Microbolometer
Pixel Pitch 25 μm
Focal Length (lens/model dependent) 9 mm, 13 mm, 19 mm 9 mm, 13 mm, 19 mm,
35 mm, 65 mm, 100 mm
Field Of View (lens/model dependent) 24° × 20° (PT-124; 9 mm)
17° × 14° (PT-117; 13 mm)
12° × 10° (PT-112; 19 mm)
48° × 39° (PT-348; 9 mm)
34° × 28° (PT-334; 13 mm)
24° × 19° (PT-324; 19 mm)
13° × 10° (PT-313; 35 mm)
7° × 5° (PT-307; 65 mm)
4.6° × 3.7° (PT-304; 100 mm)
Zoom (model dependent) 2× E-zoom 2× & 4× E-zoom
Spectral Range
Focus Range Athermalized, focus-free
2× & 4× E-zoom
13 mm, 25 mm, 35 mm,
45° × 37° (PT-645; 13 mm)
50 mm, 65 mm, 100 mm
12° × 10° (PT-612; 50 mm)
17 μm
25° × 20° (PT-625; 25 mm)
18° × 14° (PT-618; 35 mm)
10° × 8° (PT-610; 65 mm)
6.2° × 5° (PT-606; 100 mm)
Resolution
320 x 240160 x 120 640 x 480
25 μm
Continuous e-zoom
on PT-6xxE models
OUTPUTS
CONTROL
PAN / TILT PERFORMANCE
GENERAL
Composite Video NTSC or PAL Standard
Video Over Ethernet Two independent channels of streaming MPEG-4, H.264, or M-JPEG
for each of two cameras.
Point To Point (stand alone) Standard
Ethernet Standard
Serial RS-232/-422; Pelco D, Bosch
Network Enabled Standard
Pan Angle/Speed Continuous 360°; 0.1° to 70°/sec
Tilt Angle/Speed +90° to -90°; 0.1° to 30°/sec
Weight 36 lb (configuration dependent)
Dimensions (L,W,H) 13.7” × 18.4” × 12.8” (348 mm × 467 mm × 326 mm)
Power Requirements 24 VAC (21-30 VAC)
24 VDC (21-30 VDC)
Power Consumption 24 VAC: 85 VA max no heater, 215 VA ma x w/hea te r
24 VDC: 65 W max no heater, 195 W max w/heater
DAY/NIGHT CCD CAMERA Sony FCB-EX1010
Sensor Type 1/4” Exview HAD CCD
Lens Field Of View
Focal Length
Zoom
F/#
57.8° (h) to 1.7° (h)
3.4 mm to 122.4 mm
36× Optical zoom, 12× E-zoom
1.6 to 4.5
Effective pixels (NTSC) 380,000
ENVIRONMENTAL
Dust, Water Protection Rating IP66
Operating Temperature -40°C to +55°C (-40°F to +130°F)
Inrush Current
<10 A for DC power supply with slew rate > 10 ms
<38 A for AC power supply with slew rate > 4.17 ms
