Ford Escape 2013 Manual

22
December 2011
esourcebook.dealerconnection.com
RE&T: 2013 Source Book
Escape
Escape
Comfort/Convenience
2013
BLIS (Blind Spot Information System) with
Cross-traffic Alert
BLIS
• Alertsthedriverifanothervehicleentersthe“blind
zone” by utilizing two radar sensors located behind
each rear wheel and concealed by the rear fascia
• Blindzoneextendsfromtherearviewmirrorsrearward
to approximately 10 feet behind the rear bumper
• Eachexteriorrearviewmirrorisequippedwithan
amber indicator light
– Mirror indicator illuminates when a vehicle in an
adjacent lane enters the blind zone from behind
• Systemwillnotbeactivatedbyanovertaken/passed
vehicle unless that vehicle remains in the zone for
more than 3 seconds
• Systemisautomaticallyengagedwhenthevehicle
is placed in Drive and is not designed to detect
pedestrians or cyclists
• Systemcanbeturnedoffthroughtheleftinstrument
cluster screen but defaults to “on” when the vehicle
is restarted
• Ifaradarsensorbecomesblockedbywetsnowor
mud, the blind spot alert indicators will illuminate
and the message center will display:
–CLEANRADAR—SEEMANUAL
Cross-traffic Alert
• Warnsthedriverofapproachingvehicleswhen
slowly backing out of a parking spot
– Mirror indicator is illuminated and a series of tones
are sounded if an oncoming vehicle is detected
– Mirror indicator light will illuminate in the left
or right exterior mirror to indicate direction of
oncoming vehicle
– Depending on the direction in which an
approaching vehicle is detected, the message
center will display:
 •VEHICLECOMINGFROMRIGHT
 •VEHICLECOMINGFROMLEFT
• Automaticallyengageswhenvehicleisplaced
in Reverse to detect moving objects within an
approximate65'rangefromeithertheleftorright
side of the vehicle
– Not designed to detect pedestrians or cyclists
• Ifaradarsensorbecomesblockedbymud,wetsnow,
etc., an alert indicator will illuminate and the left
instrument cluster screen will display:
• CLEANRADAR—SEEMANUAL
• Detectsapproachingvehiclesuptothreecarwidths
from the rear of the vehicle
• UtilizesthesameradarsensorsasBLIS
Rain-sensing Windshield Wipers
• Oncethesystemisturnedon,thereisnoneedforthe
driver to activate, deactivate or adjust the windshield
wipers under normal driving conditions
• Whensensorsmountedbehindtherearviewmirror
detect moisture on the windshield, the windshield
wipers are automatically activated at the appropriate
speed to keep the windshield clear
• Systemmustbeturnedoffbeforeenteringan
automatic car wash
Automatic Headlamps with Wiper Activation
• Automaticallyactivatestheheadlampsandtaillamps
ifthewipersarebeingused—helpingthedriversee
and the vehicle be seen in inclement weather
• Whentheheadlampswitchisinautoposition
and the front wipers are activated in any mode
except mist or wash, the vehicle headlamps will
automatically turn on within 3 seconds
• Oncethefrontwipersaredeactivated,the
headlamps will automatically turn off within
30 seconds
• OnEscapemodelswithautomaticheadlamps
Driver Assistance Technologies cont’d
MAKE THE POINT:
Rain-sensing Windshield Wipers
Be sure to understand and explain the driver-
selectable sensitivity settings on the windshield wiper
stalk. Wet the windshield by using a spray bottle, or
hose, and cycle through the sensitivity settings so the
customer can experience the difference and visually
experience how the system functions. Be sure to also
show the customer how the system is disabled via
the stalk-mounted controls. This is important since
the system must be disabled before entering an
automatic car wash.

Ford Escape 2013 Specifications

Curb Weight

curb weight 1.6L FWD	3502 lbs
curb weight 1.6L 4WD	3645 lbs
curb weight 2.0L FWD	3592 lbs
curb weight 2.0L 4WD	3732 lbs
curb weight 2.5L FWD	3515 lbs

Seating and Interior

seating capacity	5
head room front	39.9 inches
head room rear	39.0 inches
shoulder room front	56.0 inches
shoulder room rear	55.3 inches
hip room front	54.8 inches
hip room rear	52.4 inches
leg room front	43.1 inches
leg room rear	36.8 inches

Passenger and Cargo Volume

passenger volume	98.1 cu. ft.
cargo volume behind 1st row	67.8 cu. ft.
cargo volume behind 2nd row	34.3 cu. ft.
total interior volume	132.4 cu. ft.

Fuel

fuel tank capacity	15.0 gallons
fuel requirement	87 octane
fuel economy 2.5L FWD	22/31 mpg (city/hwy)
fuel economy 1.6L FWD	23/33 mpg (city/hwy)
fuel economy 1.6L 4WD	22/30 mpg (city/hwy)
fuel economy 2.0L FWD	22/30 mpg (city/hwy)
fuel economy 2.0L 4WD	21/28 mpg (city/hwy)

Engine Specifications

engine type 1.6L	EcoBoost I-4
engine type 2.0L	EcoBoost I-4
engine type 2.5L	i-VCT I-4
displacement 1.6L	97.6 cu. in.
displacement 2.0L	122 cu. in.
displacement 2.5L	152 cu. in.
horsepower 1.6L	178 @ 5700 rpm
horsepower 2.0L	240 @ 5500 rpm
horsepower 2.5L	168 @ 6000 rpm
torque 1.6L	184 lb.-ft. @ 2500 rpm
torque 2.0L	270 lb.-ft. @ 3000 rpm
torque 2.5L	170 lb.-ft. @ 4500 rpm
compression ratio 1.6L	10.0:1
compression ratio 2.0L	9.3:1
compression ratio 2.5L	9.7:1
bore and stroke 1.6L	3.11 x 3.20 inches
bore and stroke 2.0L	3.44 x 3.27 inches
bore and stroke 2.5L	3.50 x 3.94 inches
fuel system 1.6L	Direct Injection
fuel system 2.0L	Direct Injection
fuel system 2.5L	Sequential Multiport Injection

Weight and Dimensions

wheelbase	105.9 inches
length	178.1 inches
height	66.3 inches
width with mirrors	81.8 inches
width without mirrors	72.4 inches
track front	61.5 inches
track rear	61.6 inches
ground clearance	7.9 inches
