Ford Escape 2013 Manual

49
Revised May 2012
esourcebook.dealerconnection.com
RE&T: 2013 Source Book
Escape
Escape
Key Product Specifications
(1)
2013
(1) Dimensions are in inches unless otherwise specified.
(2) Figuresachievedusingpremiumunleadedgasoline.
Model 4-door
Wheelbase 105.9
Length 178.1
Height (without options) 66.3
Width (with/without mirrors) 81.8/72.4
Track (Front/Rear) 61.5/61.6
GroundClearance 7.9"
Curb Weight (approx. lbs.)
1.6L (FWD) 3502
1.6L (4WD) 3645
2.0L (FWD) 3592
2.0L (4WD) 3732
2.5L (FWD 3515
Front/Rear Seating
Seating Capacity 5
Head Room (Front/Rear) 39.9/39.0
Shoulder Room (Front/Rear) 56.0/55.3
Hip Room (Front/Rear) 54.8/52.4
Leg Room (Front/Rear) 43.1/36.8
Passenger/Luggage/Fuel Capacity
Passenger Volume (cu. ft.) 98.1
Cargo Volume (cu. ft.)
Behind 1st row 67.8
Behind 2nd row 34.3
Total Interior Volume (cu. ft.) 132.4
Fuel Tank Capacity (gal.) 15.0
Engine
Engine Layout Front engine, front drive/Intelligent 4WD
Engine Type 1.6L 2.0L 2.5L
EcoBoost I-4 EcoBoost I-4 i-VCT I-4
Displacement 1.6L, 97.6 2.0L, 122 2.5L, 152
(liters/cu. in.)
Horsepower @ rpm 178 @ 5700 240 @ 5500
(2)
168 @ 6000
Torque (lb.-ft. @ rpm) 184 @ 2500 270 @ 3000
(2)
170 @ 4500
Compression Ratio 10.0:1 9.3:1 9.7:1
Bore and Stroke 3.11 x 3.20 3.44 x 3.27 3.50 x 3.94
Fuel System Direct Direct Sequential
Injection Injection Multiport
Fuel Requirement 87 octane 87 octane 87 octane
(min.) (min.) (min.)
Fuel Economy 22/31 (2.5L FWD)
(city/hwy.) 23/33 (1.6L FWD)
22/30 (1.6L 4WD
22/30 (2.0L FWD)
21/28 (2.0L 4WD)
Exhaust System Single stainless steel with catalytic converter
Transmissions
Type 6-speed SelectShift Automatic
Final Drive Ratio 2.5L (FWD) 3.51:1
1.6L (FWD) 3.21:1
1.6L (4WD) 3.51:1
2.0L (FWD) 3.07:1
2.0L (4WD) 3.07:1
Gear Ratios
Gears 1st 2nd 3rd 4th 5th 6th Rev.
6-speed 4.58:1 2.96:1 1.91:1 1.44:1 1.00:1 0.74:1 2.94:1
SelectShift Auto.
Front Suspension
Type Independent MacPherson struts
Springs Coil
Shock Absorbers Gas-pressurized hydraulic
StabilizerBar(dia.) 24mmsolid(18"wheels)
25mmhollow(17",19"wheels)
Rear Suspension
Type Independent double lateral link
semi-trailing arms
Springs Coil
Shock Absorbers Gas-pressurized hydraulic
Stabilizer Bar (dia.) 18mmsolid(18"wheels)
19.5mmsolid(17",19"wheels)
Steering
Type Rack-and-pinion with electric power-
assist (EPAS)
Overall Ratio 15.2:1
TurningDiameter, 38'8"
Curb-to-Curb (ft.)
Brakes
Standard Four-wheel discs with Anti-lock
Braking System (ABS)
Trailer Towing
Towing Class Light Duty Class I (2.5L,1.6LEcoBoost,
2.0LEcoBoost)
Medium Duty Class II (2.0L EcoBoostwith
TrailerTowPackage)
Gross Trailer 1500 lbs. max.or less (2.5L)
Weight (lbs.) 2000lbs.maxorless(1.6LEcoBoost,
2.0LEcoBoost)
3500 lbs. max.or less (2.0L EcoBoost with
TrailerTowPackage)
Maximum Tongue 150 lbs.(2.5L)
Load (lbs.) 200lbs.(1.6LEcoBoost,2.0LEcoBoost)
350 lbs. (2.0L EcoBoost withTrailerTow
Package)
Hitch Design Load-carrying
Flat/Neutral Towing
Emergency Towing It is recommended that Escape be towed
with a wheel lift or with flatbed equipment.
However, if towing in an emergency only,
Escape may be neutral-towed behind another
vehicle, but only at a maximum speed of
35 mph and for a distance of no greater than
50 miles.
RecreationalTowing •WhentowingEscapebehindanothervehicle,
such as an RV, a front-wheel dolly or flatbed
trailer must be used
  •FWDmodelscanbeflat-towedwithafront-
wheel dolly
  •4WDmodelsMUST use a flatbed trailer with
all four wheels off the ground. The use of a
front-wheel dolly may cause damage to the
transmission and 4WD system

Ford Escape 2013 Specifications

Curb Weight

curb weight 1.6L FWD	3502 lbs
curb weight 1.6L 4WD	3645 lbs
curb weight 2.0L FWD	3592 lbs
curb weight 2.0L 4WD	3732 lbs
curb weight 2.5L FWD	3515 lbs

Seating and Interior

seating capacity	5
head room front	39.9 inches
head room rear	39.0 inches
shoulder room front	56.0 inches
shoulder room rear	55.3 inches
hip room front	54.8 inches
hip room rear	52.4 inches
leg room front	43.1 inches
leg room rear	36.8 inches

Passenger and Cargo Volume

passenger volume	98.1 cu. ft.
cargo volume behind 1st row	67.8 cu. ft.
cargo volume behind 2nd row	34.3 cu. ft.
total interior volume	132.4 cu. ft.

Fuel

fuel tank capacity	15.0 gallons
fuel requirement	87 octane
fuel economy 2.5L FWD	22/31 mpg (city/hwy)
fuel economy 1.6L FWD	23/33 mpg (city/hwy)
fuel economy 1.6L 4WD	22/30 mpg (city/hwy)
fuel economy 2.0L FWD	22/30 mpg (city/hwy)
fuel economy 2.0L 4WD	21/28 mpg (city/hwy)

Engine Specifications

engine type 1.6L	EcoBoost I-4
engine type 2.0L	EcoBoost I-4
engine type 2.5L	i-VCT I-4
displacement 1.6L	97.6 cu. in.
displacement 2.0L	122 cu. in.
displacement 2.5L	152 cu. in.
horsepower 1.6L	178 @ 5700 rpm
horsepower 2.0L	240 @ 5500 rpm
horsepower 2.5L	168 @ 6000 rpm
torque 1.6L	184 lb.-ft. @ 2500 rpm
torque 2.0L	270 lb.-ft. @ 3000 rpm
torque 2.5L	170 lb.-ft. @ 4500 rpm
compression ratio 1.6L	10.0:1
compression ratio 2.0L	9.3:1
compression ratio 2.5L	9.7:1
bore and stroke 1.6L	3.11 x 3.20 inches
bore and stroke 2.0L	3.44 x 3.27 inches
bore and stroke 2.5L	3.50 x 3.94 inches
fuel system 1.6L	Direct Injection
fuel system 2.0L	Direct Injection
fuel system 2.5L	Sequential Multiport Injection

Weight and Dimensions

wheelbase	105.9 inches
length	178.1 inches
height	66.3 inches
width with mirrors	81.8 inches
width without mirrors	72.4 inches
track front	61.5 inches
track rear	61.6 inches
ground clearance	7.9 inches
