Fronius SYMO Series User Manual

Technical data
Fronius Symo 10.0-3 208-240 12.0-3 208-240
Input data
MPP voltage range 300 - 500 V DC
Input voltage range (at 1000 W/m²/14 °F in an open circuit) 200 - 600 V DC
Max. input current (MPP1/MPP2)
(MPP1 + MPP2)
25.0/16.5 A
41.5 A
Max. short circuit current of solar modules (I
SC PV
) (MPP1/
MPP2)
37.5 / 24.8 A
Max. inverter backfeed current to the array
1)
0.0 A
2)
Output data
Nominal output power (P
nom
) 9995 W 11,995 W
Max. output power (+104 °F) 9995 W 11,995 W
Max. output power (+140 °F)
at 208 V 8000 W 8000 W
at 220 V 8600 W 8600 W
at 240 V 8600 W 8600 W
Rated apparent power 9995 VA 11,995 VA
Phases 3 ~ NPE
Nominal grid voltage
at 208 V 120/208 V
at 220 V 127/220 V
at 240 V 120/240 V
Operating range AC voltage -12 to +10%
Adjustment range for grid voltage 60 - 152 V/104 - 288 V
Max. continuous output current at V
nom
at 208 V 27.7 A 33.3 A
at 220 V 26.2 A 31.5 A
at 240 V 24.0 A 28.9 A
Recommended min. AC overcurrent protection
at 208 V 35.0 A 45.0 A
at 220 V 35.0 A 40.0 A
at 240 V 30.0 A 40.0 A
Max. output fault current per duration 43.1 A / 158.4 ms
Nominal frequency
50/60 Hz
Total harmonic distortion < 1.5% < 1.75%
Power factor (cos phi)
0 - 1 ind./cap.
3)
General data
Maximum efficiency 97.00%
