Fujitsu WGYA050DG6 User Manual

- (OU01 - 05) -
Outdoor unit / Single phase
OUTDOOR UNIT WO

A060-100LF
OUTDOOR UNIT WO

A060-100LF
TECHNICAL SPECIFICATIONS2-2.
Model name (Outdoor unit) WO

A060LFCA WO

A080LFCA WO

A100LFTA
Enclosure
Colour
BEIGE
Apporoximate colour of MUNSELL 10YR 7.5/1.0
Material Steel sheet
Dimensions
(H x W x D)
Net
mm
620 × 790 × 290 830 × 900 × 330
Gross 712 × 935 × 400 970 × 1050 × 445
Weight
Net
kg
41 42 60
Gross 45 45 67
Heat exchanger type
Dimensions (H x W x D)
mm
588 × 881 × 36.4
Main: 588 × 881 × 36.4
Sub: 546 × 580 × 18.2
798 × 900 × 36.4
Fin pitch 1.3 1.45 1.3
Rows & Stages 2 × 28
Main: 2 × 28
Sub: 1 × 26
2 × 38
Pipe type Copper
Fin
Type (Material) Corrugate (Alminium)
Surface treatment Corrosion resistance
Corrosion resistance
(Blue n)
Fan
Airow rate Heating m³/h 2070 2340 3600
Type x Q'ty Proppeller fan ×1
Discharge direction Horizontal
Motor Quantity 1
Motor output W 49 49 100
Compressor
Type x Q'ty DC 2 rotary × 1
Motor output W 1100 1100 2100
Operation range
Heating
Min °CDB -20
Max °CWB 35
Sanitary
water
Min °CDB -20
Max °CWB 35
Refrigerant
Type R410A
Charge g 1100 1400 1800
Control Expansion valve (electric type)
Nr of circuits 1
Refrigerant oil
Type POE (RB68)
Charged volume l 0.6 0.8
Connection pipe
Type
Liquid Flare connection
Gas Flare connection
Size
(Standard)
Liquid
mm
Ø 6.35 Ø 9.52
Gas Ø 12.70 Ø 15.88
Pre-charge length
m
15
Max. length 30
Min. length 5
Additional refrigerant
charge
g/m 25 40
Max. height difference m 20
Defrost method Reverse cycle
Defrost control Outdoor heat exchanger temperature sensor
Capacity control method Inverter control

Fujitsu WGYA050DG6 Specifications

General

Brand	Fujitsu
Model	WGYA050DG6
Category	Heat Pump
Language	English
