Diagnostics consumers functions
z
Various setpoints and actual values, relay switch
status and timing status data can be displayed for
purposes of diagnosis.
Outside Temperatures
LINE FUNCTION
8700 Outside temp
8701 Outside temp min
8702 Outside temp max
8703 Outside temp attenuated
8704 Outside temp composite
The current, minimum, maximum, attenuated and
c
omposite outdoor temperatures are displayed.
Heating Circuits
LINE FUNCTION
8730 and 8760 heating circuit pump 1 and 2
8731 and 8761 Heating circuit mix valve 1 open
8732 and 8762 Heating circuit mix valve 1 closed
8740 and 8770 Room temp 1 and 2
8743 and 8773 Flow temp 1 and 2
The display "Off" means that the associated
c
omponents are currently disconnected.
The display "On" means that the associated
components are currently switched on.
Cooling Circuit
LINE FUNCTION
8756 Flow temperature cooling 1
8757 Flow temperature setpoint cooling 1
The actual value of the cooling mode are displayed.
T
he cooling mode room setpoint is displayed on
programming line 8741.
