- (CS01 - 94) -
Control system
CONTROL
SYSTEM
CONTROL
SYSTEM
WIRING SPECIFICATIONS7.
OUTDOOR SENSOR7-1.
MODEL

: QAC34
Use Size Wire type Remarks
Outdoor sensor cable 0.75 mm²
2 wires connection
Max. cable length: 60 m
Use shielded (eld supplied) in
accordance with the regional
cable standard
REMOTE CONTROL (Optional parts)7-2.
MODEL

: UTW-C75XA
Use Size Wire type Remarks
Remote control cable 0.5 mm²
3 wires connection
Max. cable length: 200 m
Use shielded (eld supplied) in
accordance with the regional
cable standard
ROOM THERMOSTAT (Optional parts)7-3.
MODEL

: UTW-C55XA
Use Size Wire type Remarks
Room thermostat cable 0.5 mm²
2 wires connection
Max. cable length: 200 m
Use shielded (eld supplied) in
accordance with the regional
cable standard
RF MODULE (Optional parts)7-4.
MODEL

: UTW-MRCXD
Use Size Wire type Remarks
RF module cable 0.5 mm²
3 wires connection
Max. cable length: 200 m
Use shielded (eld supplied) in
accordance with the regional
cable standard
